Assembly instructions
Open the frame.
Fig 1a
Push the tray downwards on to the bar.
Fig 1b
Make sure the clamps are locked in place.
Loop the strap around the bar and secure with
the press stud.
Fig 1c
Slot the seat support bar on to the back of the
frame. Ensure the spring clips have come all the
way through the holes.
Fig 2
Parts list.
1. Main frame including tray, seat
cover and seat support bar
2. Front legs x 2
3. Rear legs x 2
Fig 1b
Fig 2
3
2
1
Push down
Clamp ClampStrap
Fig 1c
Fig 1a
