Operators Manual
RAM001/SB/01
11.6
. Tail gate opening in Hull frame
Problem Possible cause Correction
Bale does not come out
Density too high
Adjustment in accordance with
“Adjustment of bale density”
Hydraulic cylinder not fully open
Check stroke (220mm) of
hydraulic cylinder
Declined eld Ejection of a bale in at place
Tail gate not open
Hydraulic stop ball valve in closed condition Open the stop ball valve
Leakage or breakage of hydraulic circuit
Remedy in accordance with “
Inspection of hydraulic system
gate opening and closing”
Wrong adjustment of load bracket locking
hook
Adjustment in accordance with “
Adjustment of bale density
detection link”
Disengagement of PTO
Engage PTO & eject bale while
PTO is running
Insufcient oil in power package tank Fill oil (1.2 litre) in oil tank
Page 69
