Redline QuickLIFT - Attach Passenger Side Fender Bracket; Install Gas Springs; Remove Original Hood Prop Rod

J
eep C
h
ero
k
ee 86-01 Quic
k
LIFT Insta
ll
ation Gui
d
e
A. Repeat Steps 9-11 to attach the passenger side fender bracket. The vehicle is symmetrical so the same locators
can be used. Feel free to measure off of key areas to ensure a symmetrical installation.
Step 12 - Repeat steps 9-11 to attach the passenger fender bracket.
A. Hav
e a friend hold the hood up. Remove the stock
prop rod assembly at this time.
B. Install the driver's side gas spring with the cylinder at
the top (large end up). Be sure that the sockets snap
securely onto the ball studs. Have a friend remain
holding the hood up until Step 14 is completed. This
procedure is most easily done if the hood ends are
snapped on first and attach the lower fender ball studs
last.
Step 13 - Install Gas Springs
Step 14 - Remove prop rod.
A. Using a 10mm socket and wrench, remove the two bolts
that hold on the prop rod. Discard.
