RedMax BCZ2400S - Page 33

 33 
Key# Part Number Description Q'ty
1 T1551-12110 CYLINDER 1
2 T1551-12211 GASKET, base 1
3 4820-12130 BOLT TORX 4
4 T1551-13161 INSULATOR 1
5 T1551-13121 GASKET, insu 1
6 T1551-13131 GASKET, carb 1
7 T4950-52001 BOLT TORX 4
8 T1551-16110 COVER, tr 2
9 T1551-16142 GASKET, tr 2
10 4820-16310 BOLT TORX 4
11 T1551-21101 CRANKCASE COMP. 1
12 2629-21130 • PIN 3
13 T1551-21141 GASKET, case 1
14 06030-06001 BEARING 2
15 4810-21210 SEAL 1
16 1850-21220 SEAL 1
17 04065-02812 RING 1
18 4820-13180 BOLT TORX 3
19 T1551-41110 PISTON 1
20 5910-41210 RING 2
21 1600-41310 PIN 1
22 1260-41320 RING 2
23 1101-41331 BEARING 1
24 1101-41340 WASHER 2
25 T1551-42000 CRANKSHAFT COMP. 1
26 1650-43230 NUT 1
27 1000-43240 KEY 1
28 4810-71110 ROTOR 1
29 T1551-71200 COIL ASSY 1
30 4810-72111 • CAP 1
31 1900-72120 • SPRING 1
32 2850-71320 • TUBE 1
33 1260-71261 SPACER 2
34 4820-72150 BOLT TORX 2
35 T1551-81001 CARBURETOR ASSY 1
36 T1551-06030 • REBUILD KIT 1
37 T1551-81450 • • BODY ASSY 1
38 4810-06021 • • GASKET KIT 1
39 1850-81490 • BODY 1
40 1850-81520 • COVER 1
41 1751-81510 • PUMP 1
42 T1505-81250 • JET 1
43 1751-81240 • O-RING 1
44 1751-81130 • RING 1
45 1881-81140 • SWIVEL 1
46 1752-81110 • SCREW 2
47 5500-81120 • BRACKET 1
48 1751-81180 • NUT 1
49 1918-81170 • SCREW 1
50 1850-81530 • SCREW 4
41 5500-81160 • WASHER 1
52 4820-15310 BOLT TORX 2
53 1950-86120 CLIP 1
54 4810-15100 MUFFLER ASSY 1
55 4810-15111 • MUFFLER 1
56 4810-15140 • ARRESTER 1
57 4820-15310 BOLT TORX 2
58 T1551-15210 GASKET, muff 1
59 T1551-15220 PLATE 1
60 4820-12350 BOLT TORX 2
61 T1551-31000 HOUSING ASSY 1
Key# Part Number Description Q'ty
62 T1551-31100 • HOUSING COMP. 1
63 T1551-31110 • • HOUSING 1
64 T1700-31212 • • BRACKET(A) 1
65 T1700-31221 • • BRACKET (B) 1
66 T1700-31232 • • CUSHION 1
67 4810-31122 • DRUM 1
68 04065-02812 • RING 1
69 06002-06001 • BEARING 1
70 04064-01210 • SNAP RING 1
71 4820-13180 • BOLT TORX 2
72 4820-12350 • BOLT TORX 1
73 4820-85510 BOLT TORX 4
74 T1551-32111 COVER, engine 1
75 T4950-51010 BOLT TORX 2
76 T1551-51111 SHOE 2
77 4820-51220 SPRING 1
78 1140-51250 SCREW 2
79 1140-51230 WASHER 2
80 1140-51242 WASHER 2
81 T1551-73200 CORD COMP. 1
82 T1108-73110 SPARKPLUG 1
83 4810-72120 GROMET 1
84 T1551-75100 RECOIL ASSY 1
85 4500-75120 • REEL 1
86 4500-75150 • SCREW 1
87 1850-75130 • SPRING 1
88 4500-75180 • COLLAR 1
89 4500-75190 • ARM 1
90 4810-75160 • ROPE 1
91 3330-75421 • KNOB 1
92 4810-75170 • PLATE 1
93 4500-75210 PULIEY 1
94 4820-85510 BOLT TORX 4
95 T1551-82100 BODY-A 1
96 T1512-82130 • PLATE, choke 1
97 T1600-82140 • LEVER 1
98 T1108-82190 • SCREW 1
99 T1551-82170 ELEMENT 1
100 T1551-82200 COVER-A 1
101 T1108-82220 • KNOB 1
102 T1551-85001 TANK ASSY 1
103 T1015-85202 • CAP ASSY 1
104 4500-85300 • • HOLDER ASSY 1
105 4500-85220 • • PACKING 1
106 5601-85260 • • FILTER 1
107 4820-85260 • • STOPPER 1
108 T1551-85300 • PIPE COMP 1
109 3302-85400 • FILTER 1
110 2841-31280 • COLLER 1
111 4820-85510 BOLT TORX 3
112 T1551-31910 GUARD, tank 1
113 T1551-75410 LABEL, recoil 1
114 T1551-31130 LABEL, cover 1
115 T1551-91000 TOOL-SET 1
116 3540-91110 • BAR 1
117 T4017-91130 • SOCKET 1
118 4500-81910 COVER 1
Fig.2 ENGINE UNIT BCZ2400S (S/N 200101 and up)
