RedMax BCZ2450T - Page 71

P/L-5
BCZ2450S/T
Key# Part Number Description Q'ty
1 848-J8S-5820 PIPE COMP. 1
2 T3400-12130 • SEAL 1
3 848-JR1-58E0 SHAFT 1
4 848-JR1-6100 GEARCASE ASSY 1
5 848-JR1-61A0 • GEARCASE 1
6 04065-02612 • SNAP RING 1
7 3565-13130 • SEAL 1
8 T3002-13260 • NUT 1
9 848-JR1-61D0 • PINION 1
10 T3300-13521 • BEARING 1
11 T3403- 13510 • BEARING (0600000609) 1
12 T3300-13330 • SNAP RING 1
13 04065-02412 • RING (0243224120) 1
14 T4950-52500 • BOLT TORX, 5x25 1
15 848-JR1-61F0 • HOLDER (A) 1
16 3199-13350 • FITTING (2087061640) 1
17 01641-20608 • WASHER 1
18 T4950-51200 • BOLT TORX, 5x12 1
20 848-8R4-0600 GRIP ASSY 1
21 848-BRA-0391 • BODY-R 1
22 848-8RB-0391 • BODY-L 1
23 848-8RC-0600 • LEVER, THROTTLE 1
24 848-8RJ-0600 • SPRING, THROTTLE 1
25 848-8RD-0600 • LEVER, SAFETY 1
26 848-JL2-33F3 • SPRING 1
27 848-8RE-0600 • LEVER, JOINT 1
28 T4506-52110 • SWITCH 1
29 848-824-1600 • SCREW 4
30 848-8P4-0550 • CABLE COMP. 1
31 848-8M1-0820 • CORD COMP. 2
32 T3003-14510 • TUBE 1
33 848-8RH-0421 • BAND 2
35 4820-13180 • BOLT 2
36 848-860-5000 • NUT 2
42 T3300-17202 HANGER COMP. 1
43 848-805-2000 SCREW TORX, 5x20 1
44 848-J9U-90R0 NAME PLATE 1
45 T3195-14002 HANDLE ASSY 1
46 T4960-53030 • SCREW TORX, 5x30 4
47 T3245-24100 GUARD COMP. 1
48 T3002-24121 • BLADE 1
49 T4960-51431 • SCREW TORX, 5x14 1
50 3320-15310 • NUT 1
51 848-JC0-66C1 BRACKET 1
52 T4950-63000 BOLT TORX, 6x30 2
Key# Part Number Description Q'ty
54 848-A56-92C0 GOGGLE 1
55 MSL100 TAP HEAD COMP. 1
56 848-JR1-69L0 • ARBOR BOLT 1
57 848-JR1-69M0 • CASE 1
58 848-JR1-69U0 • EYELET 2
59 848-JR1-69Y0 • WASHER 1
60 848-JR1-69Z0 • WASHER 1
61 848-JR1-69T0 • NUT 1
62 848-JR1-69W0 • HOLDER 1
63 848-JR1-69X0 • RATCHET 1
64 848-JR1-69R0 • SPRING 1
65 848-JR1-69S0 • CORD 1
66 848-JR1-69P0 • CORD HOLDER 1
67 848-JR1-69N0 • COVER 1
68 848-8X1-0040 CAUTION LABEL 1
69 848-JR1-90S0 CAUTION LABEL 1
101 848-B50-3610 STRAP ASSY 1
Fig.2 DRIVE UNIT BCZ2450T (S/N 90200101 and up)
OPTIONAL ACCESSORIES
14. Parts list
