Key# Part Number Description Q'ty
1 T3108-12100 PIPE-C 1
2 T3400-12130 • SEAL 1
3 3520-12213 SHAFT 1
4 848-JC0-6100 GEARCASE-A 1
5 6440-13122 • GEARCASE 1
6 04065-02612 • SNAP RING 1
7 3565-13130 • SEAL 1
8 T3002-13260 • NUT 1
9 848-JC0-61D0 • PINION 1
10 T3300-13531 • BEARING 1
11 T3403- 13530 • BEARING (0600000609) 1
12 T3300-13330 • SNAP RING 1
13 04065-02412 • RING (0243224120) 1
14 T4950-52500 • BOLT TORX, 5x25 1
15 6440-13242 • HOLDER (A) 1
16 3199-13350 • FITTI (2087061640) 1
17 01641-20608 • WASHER 1
18 T4950-51200 • BOLT TORX, 5x12 1
19 3577-32141 GRIP 1
20 T3002-12202 LEVER-C 1
21 6110-14412 • LEVER 1
22 6110-14410-01
• • STAY (E50135620010) 1
23 6110-14410-02 • • COVER 1
24 T3002-12202-03 • • LEVER (E52135623511) 1
25 6110-14410-04
• • SCREW 2
26 6110-14410-05
• • NUT 2
27 6110-14410-06
• • SHAFT 1
28 6110-14410-07
• • SPRING 1
29 6110-14410-08
• • SPRING 1
30 T3032-14410-09
• • BUTTON 1
31 6110-14410-10
• • E-RING 1
32 T3002-12220 • CORD (A) 1
33 T3002-12230 • CORD (B) 1
34 T3002-12240 TUBE 1
35 T3002-83100 CABLE-C 1
36 T3300-17202 HANGER-C 1
37 848-805-2000 SCREW TORX, 5x20 1
38 848-JC0-90R1 NAME PLATE 1
39 T3195-14002 HANDLE-A 1
40 T4960-53030 • SCREW TORX, 5x30 4
41 848-JC0-6610 GUARD-C 1
42 T3002-24121 • BLADE 1
43 T4960-51431 • SCREW TORX, 5x14 1
44 3320-15310 • NUT 1
45 848-JC0-66C1 BRACKET 1
46 T4950-63000 BOLT TORX, 6x30 2
47 848-B50-3610 STRAP-A 1
48 T3002-91190 GOGGLE 1
49 PT104 Plus TAP HEAD-C 1
50 T3189-15112 • CASE 1
Key# Part Number Description Q'ty
51 T3189-15191 • EYELET 2
52 T3189-15132 • COVER 1
53 T3189-15142 • CORD HOLDER 1
54 T3189-15160 • SPRING 1
55 T3189-15180 • CORD 1
56 6019-13250 HOLDER (B) 1
101 BC00A20 BLADE KIT (PRODUCT)
102 T3246-24110 • GUARD 1
103 6367-14200 • J-HANDLE 1
104 3583-14101 • BRACKET 1
105 3540-13283 • COVER 1
106 SST229 9” 22-tooth 1
107 SST249 9” 24-tooth 1
108 SGB088 8” 8-tooth 1
109 SGB089 9” 8-tooth 1
110 SGB048 8” 4-tooth 1
111 SGB049 9” 4-tooth 1
33
Fig.1 DRIVE UNIT BCZ3000S (S/N 300001 and up)
