RedMax EB4401 - Parts List: Blower Group; Blower Group Component Details

 19 
EB4401
Fig.1 BLOWER GROUP (S/N 310001 and up)
Key# Part Number Description Q'ty
1 2750-31111 VOLUTE CASE 1
2 2750-31212 VOLUTE COVER 1
3 2750-31150 SCREW M5x25 9
4 3490-11150 ELBOW 1
5 07000-02095 O-RING 1
6 2750-31420 SCREW M5x70 2
7 3310-53331 NUT 2
8 T4012-31310 COVER INLET 1
9 2750-31150 SCREW M5x25 3
10 1140-72231 CLAMP 1
11 3407-16120 SCREW M5x14 1
12 2750-31290 TUBE 1
13 2750-31911 LABEL 1
14 T4012-32610 LABEL, net 1
15 2750-31510 FAN 1
16 3407-12210 BOLT M5x40 4
17 2750-31612 ENGINE COVER 1
18 2750-31150 SCREW M5x25 4
19 2750-72230 CLAMP 1
20 T4012-32002 FRAME ASSY 1
21 T4012-32101 • FRAME COMP 1
22 3490-21121 • RING 2
23 3460-21311 PAD 1
24 3495-21320 CLIP 4
25 2756-32300 BAND ASSY 2
26 T4012-32500 NET COMP 1
27 1480-74710 CLIP 4
28 2750-32510 DAMPER,UPPER 1
29 2750-32520 WASHER 1
30 2750-32530 SCREW M5x40 1
31 2750-32541
BOLT M5x16 (Large Washer) 2
32 2750-32610 DAMPER,LOWER 2
33 2750-32620 NUT M6 2
34 2756-85102 TANK ASSY 1
35 T1015-85202 • CAP ASSY 1
36 4500-85300 • • HOLDER ASSY 1
37 4500-85220 • • PACKING 1
38 5601-85260 • • FILTER 1
39 4820-85260 • • STOPPER 1
40 2756-85300 • PIPE COMP 1
41 3302-85400 • FILTER 1
42 1260-85460 • CLIP 1
43 3407-23610 SCREW 2
44 1100-86120 CLIP 1
61 T4017-51110 HOSE 1
62 2750-51201 SWIVEL JOINT 1
63 6811-51211 PIPE, straight 1
65 2756-51510 CLAMP 1
Key# Part Number Description Q'ty
66 2756-51520 CLAMP 1
67 3407-91000 TOOL SET 1
68 3540-91120 • SPANNER 1
69 3407-91130 • SOCKET 1
70 2756-51220 PIPE, end ø57 1
