Workshop manual
EBZ8560, EBZ8560RH
English
1662 - 003 - 04.11.2021

Table of Contents

Questions and Answers

  • T
    Tyler PearsonJul 29, 2025
    Why won't my RedMax EBZ8560 Blower start even though there's spark?
    • K
      Kimberly SimsJul 29, 2025
      If your RedMax Blower isn't starting despite having a spark, it could be due to several reasons. There might be too much fuel in the engine; in this case, drain the fuel and adjust or replace the carburetor. The air filters could be dirty, requiring you to clean the foam air filter and replace the paper air filter. The fuel type might be incorrect or not mixed properly, so replace it with the correct type and mixture. Other potential causes include a loose spark plug (tighten it), worn or damaged cylinder/piston rings (replace them), a leakage between the cylinder and crankcase (replace the cylinder base gasket), a carburetor needing adjustment, dirt in the carburetor or fuel line (clean them), a dirty fuel filter (clean or replace it), or a crankcase leakage (replace the seal ring).
  • L
    Lori AdamsAug 4, 2025
    How to increase airflow on a RedMax Blower?
    • L
      leekristinAug 4, 2025
      If the airflow of your RedMax Blower is not sufficient, the air filters may be dirty; clean the foam air filter and replace the paper air filter. Another possible cause is a blocked muffler, which should be cleaned. Additionally, the carburetor might need adjustment or cleaning.
  • J
    jerrycraneAug 9, 2025
    What to do if my RedMax EBZ8560 Blower engine stops while running?
    • D
      Donna DrakeAug 9, 2025
      If your RedMax Blower engine stops during operation, first ensure the on/off switch is in the 'on' position. Check that the spark plug and its cap are tightened correctly. Inspect the cable to the on/off switch for disconnections or damage, and connect or replace it as needed. Examine and adjust the air gap of the ignition module if it's incorrect, and inspect the ignition module itself, replacing it if damaged. Other potential issues include a damaged engine (disassemble and examine it), dirty air filters (clean the foam and replace the paper filter), an empty fuel tank (fill it with the correct fuel), water or dirt in the fuel system (drain and refill with new fuel), or a blocked carburetor (disassemble and clean it).
  • C
    christopher39Aug 22, 2025
    What causes a RedMax EBZ8560 Blower engine to not stop?
    • V
      vthomasAug 22, 2025
      If your RedMax Blower engine won't stop, it could be due to the carburetor needing adjustment. Alternatively, the cooling system might be blocked, requiring you to clean the cooling fins on the cylinder and the air intake screen. The fuel type could be incorrect, or the fuel might not be mixed correctly; if so, replace it with the correct type and mixture. Deposits in the combustion chamber could also be the cause, necessitating disassembly and examination of the engine. Other possibilities include a spark plug electrode that is too hot (clean or replace the spark plug), a damaged ignition module (replace it), a broken stop switch (replace it), or disconnected/damaged wires to the stop switch (connect or replace them).
  • S
    Seth McculloughNov 14, 2025
    Why does my RedMax EBZ8560 have no power or unstable engine speed?
    • N
      Nancy MatthewsNov 14, 2025
      If your RedMax Blower has no output power or the engine speed is unstable, it could be due to several reasons: air entering the fuel system (ensure all fuel line connections are tight), a damaged fuel line (examine and replace if necessary), air entering between the cylinder and crankcase (replace the cylinder base gasket), air entering through the seal between the crankcase halves (replace the seal), or water/dirt in the fuel system (drain and refill with new fuel). Other potential causes include a piston ring that cannot move freely (disassemble and examine the piston), a blocked muffler (clean it), an overheated engine (adjust the carburetor), a blocked cooling system (clean the cooling fins and air intake screen), incorrect fuel type/mixture (replace with the correct one), deposits in ...

Summary

Introduction

Safety in Introduction

Crucial safety warnings and instructions for safe operation and maintenance.

Safety

Safety Definitions

Defines warning, caution, and note symbols used in the manual for clarity.

General Safety Instructions

General precautions to follow before using the product to ensure user safety.

Special Safety Instructions

Specific safety guidelines for tasks like using compressed air or eye protection.

Prepare and Do Servicing on the Product

Maintenance Schedule

A schedule detailing daily, weekly, and monthly maintenance tasks for the service center.

Servicing Data

Servicing Data Details

Illustrated torque specifications and component data for servicing procedures.

Servicing Tools

List of Servicing Tools

Visual guide and identification of specialized tools required for maintenance and repair.

Function Overview

Product Identification

Information on identifying the product using its type plate and serial number.

Fuel Information

Details on correct fuel types, mixtures, and safe fueling procedures.

Repair Instructions

Product Overview for Repair

Labeled diagram showing main product components for reference during repair.

Starter Unit Repair

Procedures for removing, disassembling, and reassembling the starter unit.

Carburetor Repair

Comprehensive guide to carburetor disassembly, assembly, and adjustments.

Cylinder and Piston Repair

Steps for cylinder and piston removal, cleaning, inspection, and installation.

Crankshaft and Crankcase Repair

Detailed instructions for crankshaft and crankcase disassembly, cleaning, and assembly.

Handle and Throttle Trigger Repair

Procedures for disassembling and reassembling the handle and throttle trigger assembly.

Troubleshooting

Troubleshooting Guide

Common engine starting and running problems with causes and recommended solutions.

Technical Data

Technical Specifications

Key technical specifications for engine, ignition, fuel, and fan performance.

RedMax EBZ8560 Specifications

General IconGeneral
Displacement75.6 cc
Air Speed236 mph
Fuel Tank Capacity83.8 oz
Weight24.7 lbs
Air Volume977 cfm
Engine Type2-Stroke
