9. Install the foam filter (B) into the air filter cover (A).
Make sure it is set correctly.
10. Install the paper filter (C) into the air filter body (D).
Make sure it is set correctly.
CAUTION: Make sure that the text on the
paper filter is up when you install the paper
filter.
11. Install the air filter cover (A) to the air filter body (D)
with the knobs (E).
7.7 Carburetor
7.7.1 Carburetor parts
The carburetor can be divided into 3 different function
units: the metering unit, the blending unit, and the pump
unit.
1662 - 003 - 04.11.2021 Repair instructions - 17
