9 Technical data
9.1 Technical data
EBZ8560 EBZ8560RH
Engine
Cylinder displacement, cm
3
75.6 75.6
Idle speed, rpm 2000 2000
Operating speed, rpm 7500 7500
Carburetor type Walbro WYA-237A Walbro WYA-237A
Ignition system
1
Spark plug NGK CMR7H NGK CMR7H
Electrode gap, mm / in. 0.6–0.7 / 0.024–0.028 0.6–0.7 / 0.024–0.028
Ignition timing, º/rpm 34/7500 34/7500
Fuel and lubrication system
Fuel tank capacity, l / US pint 2.3 / 4.9 2.3 / 4.9
Weight
Weight, kg / lb 11.6 / 25.5 11.5 / 25.4
Fan performance
Pipe nozzle diameter, mm / in. 86 / 3.386 86 / 3.386
Maximum air velocity with standard nozzle, mph / m/s 220 / 98 220 / 98
Air flow with standard nozzle, cfm / m
3
/min 1000 / 28 1000 / 28
1
The spark ignition system complies with the Canadian ICES-002 standard.
1662 - 003 - 04.11.2021 Technical data - 47
