RedMax EBZ8560 - Servicing Data; Servicing Data Details

4 Servicing data
4.1 Servicing data
■ Lubricate with two-stroke oil.
● Lubricate with grease.
2–3 Nm T27
2–3 Nm T27
3x 1.5–2 Nm
2x 3–4.5 Nm T27
4x 4–6 Nm T27
2x 2.5–4 Nm
T27
25–35 Nm 14 mm
5x 3–4 Nm T27
8–12 Nm T27
2x 8–12 Nm
T27
4x 2–3 Nm T27
9–13 Nm 16 mm
2x 3–4 Nm
T27
4x 6–9 Nm T27
4x 3–4.5 Nm T27
4x 6–8 Nm T27
4x 6–8 Nm
T27
6 - Servicing data 1662 - 003 - 04.11.2021
