RedMax EB6200 - Page 15

Fig.1 CARBURETOR COMPONENTS
Key# Part Number Description Q'ty
1 1850-81450 Body ass’y 1
2 3306-81380 Screen 1
3 3356-81310 Valve 1
4 1850-81270 Spring 1
5 1850-81220 Screw 1
6 3310-81250 Pin 1
7 3310-81230 Lever 1
8 1850-81490 Body 1
9 1850-81520 Cover 1
10 1751-81510 Pump 1
11 5500-81160 Washer 1
12 1881-81140 Swivel 1
13 1751-81130 Ring 1
14 1065-81410 Gasket 1
15 1065-81420 Diaphragm 1
16 1850-81470 Gasket 1
17 3310-81260 Diaphragm 1
18 1752-81110 Screw 2
19 5500-81120 Bracket 1
20 1751-81180 Nut 1
21 1918-81170 Screw 1
22 1881-81130 Ring 1
23 1850-81530 Screw 4
24 2750-81250 Jet 1
25 1751-81240 O-Ring 1
26* ————— Body 1
27* ————— Valve ass’y 1
Key# Part Number Description Q'ty
❲ 13 ❳
[NOTE]
• 26*-Body and 27*-Valve ass’y are not supplied
as an individual part respectively, but supplied
as a carburetor ass’y (P/NO. 2750-81000).
EB6200
