EB6200
Fig.2 ENGINE GROUP
Key# Part Number Description Q'ty
1 2750-12110 Cylinder 1
2 2750-12210 Gasket, base 1
3 2750-12130 Bolt 4
4 1484-13160 Insulator 1
5 2750-13130 Gasket 1
6 1460-13132 Gasket 1
7 0263-90535 Screw 2
8 2750-12510 Cover 1
9 2750-12520 Bolt 2
10 2756-15100 Muffler ass’y 1
11 1421-15120 Arrester 1
12 2750-15210 Gasket 1
13 2750-15160 Bolt 2
14 2750-15170 Bolt 1
15 2750-21100 Crankcase comp 1
16 2750-21140 Gasket 1
17 2810-21240 Bearing 3
18 1520-21220 Oil seal 1
19 1400-21220 Oil seal 1
20 01252-30530 Bolt 4
21 04065-03515 Snap ring 1
22 2750-21210 Cover 1
23 1565-72211 Bolt 1
24 2750-41110 Piston 1
25 3366-41210 Ring 2
26 3366-41310 Piston pin 1
27 3350-41320 Snap ring 2
28 1400-41410 Bearing 1
29 2616-41510 Washer 2
30 2750-42000 Crankshaft comp 1
31 1300-42410 Shim 0~1
32 1400-43230 Nut 2
33 1000-43240 Key 1
34 2750-71110 Rotor 1
35 2750-71200 Coil ass’y 1
36 2750-72150 Bolt 2
37 1900-72111 Cap 1
38 1900-72120 Spring 1
39 5500-72130 Grommet 1
40 5602-73110 Spark plug 1
(Champion RCJ6Y)
41 2751-71220 Cap 1
42 2750-73200 Cord comp 1
43 1487-75100 Recoil ass’y 1
44 1180-75221 Spring 1
45 1487-75120 Reel 1
Key# Part Number Description Q'ty
46 1487-75140 Dog 1
47 1861-75150 Washer 1
48 1483-75270 Screw 1
49 1487-75160 Retainer 1
50 1487-75170 Washer 1
51 1400-75160 Rope 1
52 1400-75170 Knob 1
53 1487-75211 Pulley 1
54 3460-75510 Bolt 4
55 2750-75611 Label 1
56 2750-81000 Carburetor 1
57 3407-82102 Body ass’y 1
58 3407-82130 Plate 1
59 3407-82140 Lever 1
60 2630-33610 Screw 1
61 1487-82200 Cover ass'y 1
62 1487-82210 Knob 1
63 1491-82311 Element 1
64 1484-82510 Plate 1
65 0263-90560 Screw 2
66 1491-82352 Screen 1
67 1491-82360 Screw 1
68 1133-82060 Label 1
69 2750-21510 Bolt 6
101 2750-05011 Short block OP
102 2750-06010 Gasket kit OP
103 2750-96100 Puller ass’y OP
104 3350-96220 Stopper OP
105 2750-96230 Guide OP
106 2750-96240 Gauge OP
