EB6200
Fig.3 BLOWER GROUP
Key# Part Number Description Q'ty
1 2750-31110 Volute case 1
2 2750-31210 Volute cover 1
3 2750-31150 Screw 9
4 3490-11150 Elbow 1
5 07000-02095 O-Ring 1
6 2750-31420 Screw 2
7 3310-53331 Nut 2
8 2750-31310 Cover lnlet 1
9 2750-31150 Screw 3
10 1140-72231 Clamp 1
11 3407-16120 Screw 1
12 2750-31290 Tube 1
13 2750-31510 Fan 1
14 3407-12210 Bolt 4
15 2750-31612 Engine cover 1
16 2750-31150 Screw 4
17 2756-32100 Frame comp 1
18 3490-21120 Ring 2
19 3460-21311 Pad 1
20 3495-21320 Clip 4
21 2756-32300 Band ass’y 2
22 2750-32510 Damper, upper 1
23 2750-32520 Washer 1
24 2750-32530 Screw 1
25 2750-32540 Bolt 2
26 2750-32610 Damper, lower 2
27 2750-32620 Nut 2
28 2756-85100 Tank ass’y 1
29 4550-85200 Cap ass’y 1
30 5600-85250 Valve 1
31 4500-85220 Packing 1
32 4500-85230 Holder 1
33 5600-85240 Cap 1
34 2750-85300 Pipe comp 1
35 3302-85400 Filter 1
36 1260-85460 Clip 1
37 3407-23610 Screw 2
38 1100-86120 Clip 1
39 3407-25000 Lever set 1
40 3495-25110 Lever 1
41 3310-53331 Nut 1
42 01642-20508 Washer 1
43 3495-25212 Arm 1
44 3495-25310 Bracket 1
45 3495-25410 Bolt 1
46 3495-25420 Spring 1
Key# Part Number Description Q'ty
47 3495-25440 Washer 1
48 01584-00605 Nut 1
49 3495-25450 Washer 2
50 3495-25510 Switch 1
51 3407-83110 Cable comp 1
52 3495-25810 Tube 1
53 2750-32540 Bolt 2
54 2750-31910 Label 1
55 2750-51110 Hose 1
56 2750-51200 Swivel joint 1
57 6811-51210 Pipe, straight 1
58 6811-51220 Pipe, end 1
59 2756-51510 Clamp 1
60 2756-51520 Clamp 1
61 2750-51500 Grip ass’y 1
62 3495-51420 Wing bolt 1
63 3495-51430 Wing nut 1
64 3238-15230 Washer 2
65 2750-91000 Tool set 1
66 3540-91120 Spanner 1
67 2750-91130 Socket 1
