EB7000
Fig.1 BLOWER GROUP (S/N 010001 and up)
Key# Part Number Description Q'ty
1 2750-31111 VOLUTE CASE 1
2 2750-31211 VOLUTE COVER 1
3 2750-31150 SCREW M5x25 9
4 3490-11150 ELBOW 1
5 07000-02095 O-RING 1
6 2750-31420 SCREW M5x70 2
7 3310-53331 NUT 2
8 T4012-31310 COVER INLET 1
9 2750-31150 SCREW M5x25 3
10 1140-72231 CLAMP 1
11 3407-16120 SCREW M5x14 1
12 2750-31290 TUBE 1
13 2750-31911 LABEL 1
14 T4012-32610 LABEL, net 1
15 2750-31510 FAN 1
16 3407-12210 BOLT M5x40 4
17 2750-31612 ENGINE COVER 1
18 2750-31150 SCREW M5x25 4
19 2750-72230 CLAMP 1
20 T4012-32000 FRAME ASSY 1
21 T4012-32100 • FRAME COMP 1
22 3490-21120 • RING 2
23 3460-21311 PAD 1
24 3495-21320 CLIP 4
25 2756-32300 BAND ASSY 2
26 T4012-32500 NET COMP 1
27 1480-74710 CLIP 4
28 2750-32510 DAMPER,UPPER 1
29 2750-32520 WASHER 1
30 2750-32530 SCREW M5x40 1
31 2750-32540
BOLT M5x16 (Large Washer)
2
32 2750-32610 DAMPER,LOWER 2
33 2750-32620 NUT M6 2
34 T4012-85100 TANK ASSY 1
35 4500-85200 • CAP ASSY 1
36 4500-85300 •• HOLDER ASSY 1
37 4500-85220 •• PACKING 1
38 5601-85260 •• FILTER 1
39 T4012-85300 • PIPE COMP 1
40 3302-85400 • FILTER 1
41 1260-85460 • CLIP 1
42 3407-23610 SCREW 2
43 1100-86120 CLIP 1
44 T4012-85190 LABEL 1
45 T4012-25000 LEVER SET 1
46 T4012-25100 • LEVER 1
47 3310-53331 • NUT M5 1
48 01642-20508 • WASHER 1
49 T4012-25210 • ARM 1
50 T4012-25310 • BRACKET 1
Key# Part Number Description Q'ty
51 3495-25410 • BOLT 1
52 3495-25420 • SPRING 1
53 3495-25440 • WASHER 1
54 01584-00605 • NUT 1
55 3495-25450 • WASHER 2
56 T4012-25510 • SWITCH 1
57 T4012-83110 • CABLE COMP 1
58 4900-72141 • TUBE 1
59 2750-32540 BOLT 2
60 T4012-82110 BODY, cleaner 1
61 T4012-82200 COVER ASSY 1
62 T4012-82220 • COVER 1
63 2750-31150 • SCREW 2
64 T4012-82800 • KNOB BOLT 2
65 T4012-82290 • LABEL, cleaner 1
66 T4012-82310 ELEMENT 1
67 T4012-82320 ELEMENT 1
68 T4012-82610 HOSE 1
69 T4012-82620 BAND (
φ 68) 1
70 T4012-82630 BAND (φ 40) 1
71 T4012-82640 LABEL, choke 1
72 00263-20520 SCREW 4
73 T4012-82710 NUT 4
74 2750-51110 HOSE 1
75 2750-51200 SWIVEL JOINT 1
76 6811-51210 PIPE, straight 1
77 6811-51220 PIPE, END φ 66 1
78 2756-51510 CLAMP 1
79 2756-51520 CLAMP 1
80 2750-51500 GRIP ASSY 1
81 3495-51420 • WING BOLT 1
82 3495-51430 • WING NUT 1
83 3238-15230 • WASHER 2
84 2750-91000 TOOL SET 1
85 3540-91120 • SPANNER 1
86 2750-91130 • SOCKET 1
87 2756-51220 PIPE, end φ 57 OP
❲
19
❳
