RedMax EB7001 - Page 23

23
EB7001/EB7001RH
Fig.1 BLOWER GROUP (S/N 200101 and up)
Key# Part Number Description Q'ty
1 2750-31111 VOLUTE CASE 1
2 2750-31212 VOLUTE COVER 1
3 2750-31150 SCREW M5x25 9
4 T4030-31410 ELBOW 1
5 07000-02095 O-RING 1
6 2750-31420 SCREW M5x70 2
7 3310-53331 NUT 2
8 T4030-31310 COVER INLET 1
9 2750-31150 SCREW M5x25 3
10 1140-72231 CLAMP 1
11 3407-16120 SCREW M5x14 1
12 2750-31290 TUBE 1
13 2750-31911 LABEL 1
14 T4012-32610 LABEL, net 1
15 2750-31510 FAN 1
16 3407-12210 BOLT M5x40 4
17 2750-31612 ENGINE COVER 1
18 2750-31150 SCREW M5x25 4
19 2750-72230 CLAMP 1
20 T4012-32001 FRAME ASSY 1
21 T4012-32101 • FRAME COMP 1
22 3490-21121 • RING 2
23 T4030-32410 PAD 1
24 3495-21320 CLIP 6
25 2756-32300 BAND ASSY 2
26 T4012-32500 NET COMP 1
27 1480-74710 CLIP 4
28 2750-32510 DAMPER,UPPER 1
29 2750-32520 WASHER 1
30 2750-32530 SCREW M5x40 1
31 2750-32541
BOLT M5x16 (Large Washer) 2
32 2750-32610 DAMPER,LOWER 2
33 2750-32620 NUT M6 2
34 T4012-85101 TANK ASSY 1
35 T1015-85202 • CAP ASSY 1
36 4500-85300 •• HOLDER ASSY 1
37 4500-85220 •• PACKING 1
38 5601-85260 •• FILTER 1
39 4820-85260 •• STOPPER 1
40 T4012-85300 • PIPE COMP 1
41 3302-85400 • FILTER 1
42 1260-85460 • CLIP 1
43 3407-23610 SCREW 2
44 1100-86120 CLIP 1
47 T4012-82110 BODY, cleaner 1
48 T4012-82200 COVER ASSY 1
49 T4012-82220 • COVER 1
50 2750-31150 • SCREW 2
Key# Part Number Description Q'ty
51 T4012-82800 • KNOB BOLT 2
52 T4030-82290 • LABEL, cleaner 1
53 T4012-82311 ELEMENT 1
54 T4012-82320 ELEMENT 1
55 T4012-82610 HOSE 1
56 T4012-82620 BAND (ø68) 1
57 T4012-82630 BAND (ø40) 1
58 T4012-82640 LABEL, choke 1
59 00263-20520 SCREW 4
60 T4012-82710 NUT 4
61 T4030-51110 HOSE 1
62 2750-51201 SWIVEL JOINT 1
63 6811-51211 PIPE, straight 1
64 6811-51220 PIPE, END ø66 1
65 T4030-51510 CLAMP 1
66 2756-51520 CLAMP 1
67 2750-91000 TOOL SET 1
68 3540-91120 • SPANNER 1
69 2750-91130 • SOCKET 1
70 2756-51220 PIPE, end ø57
*Acc
*Acc: Accessory, which is not included in standard package.
