EBZ5100/EBZ5100RH/EBZ5100-CA/EBZ5100RH-CA
Fig.1 BLOWER GROUP (S/N 70100001 and up)
Key# Part Number Description Q'ty
1 848-L3H-55A0 VOLUTE CASE 1
2 848-L3H-55B1 VOLUTE COVER 1
3 T4970-52510 SCREW M5x25 10
4 T4030-31410 ELBOW 1
5 07000-02095 O-RING 1
6 T4960-57030 SCREW M5x70 2
7 3310-53331 NUT 2
8 848-L3H-55D0 FUNNEL 1
9 T4970-52510 SCREW M5x25 3
10 2750-72230 CLAMP 1
11 T4970-51410 SCREW M5x14 1
12 2750-31290 TUBE 1
13 2750-31911 LABEL 1
14 T4012-32610 LABEL, net 1
15 T4017-31510 FAN 1
16 848-816-3500 BOLT M6x35 4
17 848-L3H-31A0 ENGINE COVER 1
18 T4970-52510 SCREW M5x25 5
20 848-L5C-3501 FRAME ASSY 1
21 848-L5C-3510 • FRAME COMP. 1
22 3490-21121 • RING 2
23 848-L5C-35C0 PAD 1
24 3495-21320 CLIP 6
25 848-L30-3611 BAND ASSY 2
26 848-L53-3521 NET COMP. 1
27 1480-74710 CLIP 4
28 2750-32510 DAMPER, UPPER 1
29 848-870-5040 WASHER 1
30 T4972-54010 SCREW 1
31 T4960-51631 SCREW M5x16 (Large Washer) 2
32 2750-32610 DAMPER, LOWER 2
33 2750-32620 NUT M6 2
34a 848-L5K-8510 TANK ASSY 1
34b 848-L5L-8500 TANK ASSY (CA only)
35 T1015-85202 • CAP ASSY 1
36 4500-85300 • • HOLDER ASSY 1
37 4500-85220 • • PACKING 1
38 5601-85260 • • FILTER 1
39 4820-85260 • • STOPPER 1
40 T4012-85300 • PIPE COMP. 1
41 3302-85400 • FILTER 1
42 1260-85460 • CLIP 1
43 T4960-51231 SCREW M5x12 (Large Washer) 2
44 1950-86120 CLIP 1
Key# Part Number Description Q'ty
61 T4030-51110 HOSE 1
62 2750-51201 SWIVEL JOINT 1
63 6811-51211 PIPE, straight 1
64 6811-51220 PIPE, END 1
65 848-8K4-0060 CLAMP 1
66 848-8K4-0030 CLAMP ø115 1
67 848-8U0-0020 TOOL SET 1
68 3540-91120 • SPANNER 1
69 848-8U1-0020 • SOCKET 1
74 848-8X5-0710 LABEL, sound 1
75 848-C1B-90G0 LABEL, hotmark 1
