13
• Mount The Rear Camera
Open the trunk of the vehicle, remove the screws, remove the
plastic panel.
P open the license plate light and pass the rear camera cable
through the hole where the license plate light is located.
1
• Wire Layout In The Vehicle
The car charger is connected to the cigar socket.
Connect the other end of the car charger to the dash cam.
1
2
2
Note:
This rear camera is specially designed to tolerate a variety
of environmental conditions, and is better suited installed
on the outside of the vehicle. The lens parameters are set
with the assumption that the camera will be used outside,
therefore it is recommended that you install the camera on
top of the license plate frame. If this is not possible, we have
a license plate frame bracket to solve this issue.
