DVS800 SPECIFICATION
Power Requirements 120 VAC, 1PH
MaximumFuse 15Amps
Total Amps 5 Amps
Transformer 30 VA
Blower Motor 1/3 HP ECM
Pump 1/25 HP 3-Speed
FilterSize 12”x20”x1”
ReturnDuctConnectionSize 11”x18”
Unit Technical Information
Airflow Water Return Supply Output Supply Leaving CSA P.9-11
CFM Flow Air Water BTU Air Water Certified
GPM Deg F Deg F Deg F Deg F Condition
120 28,800 104 91 -
130 34,700 111 95 -
800 2.0 70 140 40,600 117 99 Yes
150 46,500 124 103 -
160 52,400 131 106 -
Heating Capacity
Motor Speed CFM at 0.4” E.S.P. CFM at 0.8” E.S.P.
Low Velocity (0.4”) Normal 807 732
Low Velocity (0.4”) Boost 852 758
Mid Velocity (0.8”) Normal 945 805
Mid Velocity (0.8”) Boost 978 840
Blower Capacity
