REDZONE
TM
DVS SERIES AIR HANDLER MANUAL
26
DVS600 SPECIFICATION
Power Requirements 120 VAC, 1PH
MaximumFuse 15Amps
Total Amps 4 Amps
Transformer 30 VA
Blower Motor 1/3 HP ECM
Pump 1/25 HP 3-Speed
FilterSize 12”x20”x1”
ReturnDuctConnectionSize 11”x18”
Unit Technical Information
Airflow Water Return Supply Output Supply Leaving CSA P.9-11
CFM Flow Air Water BTU Air Water Certified
GPM Deg F Deg F Deg F Deg F Condition
120 22,300 105 90 -
130 27,000 112 93 -
600 1.5 70 140 31,500 119 97 Yes
150 36,100 126 101 -
160 40,700 134 104 -
Heating Capacity
Motor Speed CFM at 0.4” E.S.P. CFM at 0.8” E.S.P.
Low Velocity (0.4”) Normal 618 518
Low Velocity (0.4”) Boost 662 567
Mid Velocity (0.8”) Normal 694 609
Mid Velocity (0.8”) Boost 756 669
Blower Capacity
