WWW.REEBOKFITNESS.COM 13
12 FLOATRIDE
+
FR20 USER MANUAL
NO. PART QTY.
A01 Main Frame 1
A02 Incline Bracket 1
A03 Console Bracket 1
A04 Console Bracket Left Connecting Part 1
A05 Console Bracket Right Connecting Part 1
A06 Panel Turning Tube Bracket 1
A07 PAD Fixed Plate Spin Axis 2
A08 Left Upright Tube 1
A09 Right Upright Tube 1
B01 PAD Left Fixed Plate 2 1
B02 PAD Right Fixed Plate 2 1
B03 Motor Top Cover Tapped Plate 3
B04 Side Rail Pressing Plate 6
B05 Front Roller 1
B06 Back Roller 1
B07 Left Pulse Plate 2
B08 RIght Pulse Plate 2
B09 Safety Key Spring Plate 2
B10 Left Speaker Net 1
B11 Right Speaker Net 1
B12 Cross Wrench with Screw Driver 1
B13 5# Allen Wrench 1
B14 6# Allen Wrench 1
B15 Universal Joint Screw 2
C01 Motor Top Cover 1
C02 Motor Front Cover 1
C03 Left Upright Tube Bottom Cover 1
C04 Right Upright Tube Bottom Cover 1
C05 Back End Cover-Left 1
C06 Top Side Rail 2
C07 Left Side Rail 1
C08 Right Side Rail 1
C09 Left Upright Tube External Cover 1
C10 Right Upright Tube External Cover 1
C11 Motor Top Cover Plug 2
C12 Console Top Cover 1
C13 Console Bottom Cover 1
C14 Left Handlebar Foam 1
NO. PART QTY.
C15 Right Handlebar Foam 1
C16 Left Handlebar Side Cover 1
C17 Right Handlebar Side Cover 1
C18 Panel Top Cover 1
C19 Panel Bottom Cover 1
C20 Display Panel 1
C21 Panel Rotation Cover 2
C22 Safety Key 1
C23 Bluetooth Fixed Plate 1
C24 Left Speaker Cover 1
C25 Right Speaker Cover 1
C26 Speaker Hiding Plate 2
C27 Base of Instant Speed Button 1
C28 Base of Instant Incline Button 1
C29 Right Back End Cover 1
C30 PAD Fixed Base 1
C34 Decoration Cushion 2
C35 Button 2
C36 Button + 1
C37 Button - 1
C38 Front Foot Pad 2
C39 Running Belt 1
C40 Universal Foot Pad 2
C41 Moving Wheel 2
C42 Black Cushion 2
C43 Black Cushion 6
C44 Motor Belt 1
C45 Handlebar Plug 4
C46 EVA Pad 2
C47 EVA Pad 1
C48 Rubber Pad 2
C49 Bolt Plug 2
D01 Nut M6 10
D02 Nut M10 6
D03 Bolt M10 * 110 1
D04 Bolt M10 * 70 2
D05 Bolt M10 * 50 2
D06 Bolt M10 * 40 1
NO. PART QTY.
D07 Bolt M8 * 15 12
D08 Bolt M8 * 75 8
D09 Bolt M8 * 45 6
D10 Bolt M8 * 15 8
D11 Bolt M8 * 65 2
D12 Bolt M6 * 55 1
D13 Bolt M6 * 12 2
D14 Bolt M6 * 25 8
D15 Bolt M5 * 10 2
D16 Bolt M5 * 10 5
D17 Screw ST2.9 * 8 8
D18 Screw ST4.2 * 12 4
D19 Screw ST4.2 * 12 53
D20 Screw ST4.2 * 50 4
D22 Screw ST4.2 * 30 4
D23 Screw ST4.2 * 20 2
D24 Screw ST4.2 * 19 2
D25 Screw ST4.2 * 12 2
D26 Screw ST2.9 * 6.0 19
D27 Lock Washer Ø10 6
D28 Lock Washer Ø6 3
D29 Lock Washer Ø8 20
D30 Spring Washer Ø8 2
D31 Flat Washer Ø6 10
D32 Flat Washer Ø8 2
D33 Screw ST2.9 * 8 16
D34 Screw ST4.2 * 12 5
D35 Bolt M5 * 16 2
D36 Nut M8 14
D37 Lock Washer Ø5 2
E01 Speed Sensor Wire Length 350mm 1
E02 Blue AC Signal Wire Length 200mm 2
E03 Brown AC Signal Wire Length 350mm 1
E04 Brown AC Single Wire Length 350mm 2
E05 Green Grounding Wire Length 350mm 1
E06 Power Wire 1
E07 Power Socket 1
E08 Square Switch Button 1
NO. PART QTY.
E09 Overload Protector 1
E10 Magnet Ring 1
E11 Magnet Core 1
E12 Running Board 1
E13 Incline Motor 1
E14 DC Motor 1
E15 PCB Board 1
E16 Control Board 1
E17 Panel Top Signal Wire 1
E18 Console Top Signal Wire 1
E19 Console Middle Signal Wire 1
E20 Console Bottom Signal Wire 1
E21 Instant Speed Top Signal Wire 1
E22 Instant Speed Bottom Signal Wire 1
E23 Instant Incline Top Signal Wire 1
E24 Instant Incline Bottom Signal Wire 1
E25 Hand Pulse Top Signal Wire 1
E26 Hand Pulse Bottom Signal Wire 2
E27 Safety Key Connecting Top Wire 1
E28 Safety Key Connecting Bottom Wire 1
E32 Speaker Top Wire 2
E34 Speaker 2
E36 Light Tube 1
F01 Filter 1
F02 Inductance 1
F03 AC Signal Wire 1
F04 Grounding Wire 1
F05 Screw ST4.2 * 12 1
F06 Bolt M5 * 8 4
H01 Belt Hook 2
H02 Screw ST4.2 * 12 4
J01 Bluetooth Main Board 1
J02 Bluetooth Transfer Module 1
J03 Dongle 1
J04 Bluetooth Transfer Module Wire 1
J05 Bluetooth Wire 1
J06 Bolt 4
