Reebok FLOATRIDE+ FR30z - Product Components and Hardware; Parts Overview; Hardware Pack Contents; Assembly Steps

WWW.REEBOKFITNESS.COM 3
2 FLOATRIDE
+
FR30 USER MANUAL
A08
A09
E19
E20
A
D29
D07
D29
D07
PARTS
1
HARDWARE PACK
x2
A08 A09 A
B13 5# ALLEN
WRENCH x 1
B14 6# ALLEN
WRENCH x 1
D15 BOLT
M5*10 (x 2)
D29 LOCK
WASHER Ø8 x 14
B12 CROSS WRENCH
WITH SCREW DRIVER x 1)
B
D07 BOLT
M8*15 x 8
D10 BOLT
M8*15 (x6)
C09 C10 C03 C04 E06
C49 BOLT
PLUG x2
x2
D07 M8*15 (x 8)
D29 Ø8 (x 8)
B13 5#
E19
E20
2
