PART # DESCRIPTION QTY PART # DESCRIPTION QTY
1 Base Frame 1 36 Allen C.K.S.Full Thread Screw 2
2 Main Frame 1 37 Allen C.K.S.Full Thread Screw 4
3 Incline Frame 1 38 Philip Full Thread Screw 6
4 Round Connector Frame（Left（ 1 39 Philips C.K.S. Full Thread Screw 5
5 Round Connector Frame（Right（ 1 40 Philips C.K.S. Full Thread Screw 4
6 Flexible Tube (Inner) 1 41 Philips C.K.S. Full Thread Screw 12
7 Flexible Tube (Outer) 1 42 Philip Self-Tapping Screw 12
8 Pedal 1 43 Philip Self-Tapping Screw 18
9 Stand Post (Right) 1 44 Philip Self-Tapping Screw 4
10 Stand Post (Left) 1 45 Philip Self-Tapping Screw 25
11 Computer Frame 1 46 Philip Self-Tapping Screw 2
12
Computer Fixed Frame
1 47 Philip Self-Tapping Screw 8
13 Handle Bar Cover (Right) 1 48 Complete Console Set 1
14 Handle Bar Cover (Left) 1 49 Safety Key 1
15 Motor Frame 1 50 Front Roller 1
16 Flat Washer 17 51 Rear Roller 1
17 Washer 1 52 Hydraulic 2
18 Elastic Washer 2 53 Handle Bar Cover (Right) 1
19 Flat Washer 5 54 Handle Bar Cover (Left) 1
20 Hex Self-Locking Nut 9 55 Choke 2
21 Hex Self-Locking Nut 3 56 Metal Plug 2
22 Hex Full Thread Screw 1 57 Wire 1
23 Bolt Welding M8×65 1 58 Wire 1
24 Allen Socket Full Thread Screw 4 59 Wire 1
25 Allen Socket Full Thread Screw 2 60 Handle Pulse Wire 2
26 Allen Socket Full Thread Screw 3 61 Handle Pulse Set 2
27 Allen C.K.S. Half-Thread Screw 1 62 Controller 1
28 Allen C.K.S. Half-Thread Screw 1 63 Socket 1
29 Allen C.K.S. Half-Thread Screw 5 64 Wire (Red) L=350mm 1
30 Allen C.K.S. Half-Thread Screw 6 65 Wire (Black)L=350mm 1
31 Allen C.K.S. Half-Thread Screw 2 66 Wave Cushion 2
32 Allen C.K.S. Half-Thread Screw 8 67 Switch 1
33 Allen C.K.S. Half-Thread Screw 2 68 Fuse With Wire 1
34 Allen C.K.S.Full Thread Screw 8 69 Motor 1
35 Allen C.K.S.Full Thread Screw 8 70 Incline Motor 1
PART # DESCRIPTION QTY PART # DESCRIPTION QTY
71 Power Cord 1 106 Cylindrical Torsion Coil Spring 1
72 Speed Sensor 1 107 Handle Knob 1
73 Running Belt 1 108 Feet Pad 2
74 Motor Cover 1 109 Philips C.K.S. Full Thread Screw 2
75 Rear Pad 10 110 Philip Full Thread Screw 2
76 Side Rail 2 48-1 Console Housing (Upper) 1
77 Feet Pad (Right) 1 48-2 Console Housing (Bottom) 1
78 Feet Pad (Left) 2 48-3 Display Frame (Bottom) 1
79 Slider 1 48-4 Console Set 1
80 Roundness Side Rail Guider 1 48-4-1 Display Frame (Upper) 1
81 Roundness Side Rail Guider 1 48-4-2 Blade 3
82 Pipe Plug 3 48-4-3 Card 1
83 Hollow Pipe Plug 6 48-4-4 Fixed Block 1
84 Hollow Pipe Plug 1 48-5 Central Parts Of Console 1
85 Motor Belt 1 48-5-1 Main Overlay 1
86 Cushion 1 48-5-2 Speaker (L) 1
87 Columnar Cushion 2 48-5-3 Speaker (R) 1
88 Feet Pad 2 48-5-4 Ipad Pallet 1
89 Wheel 2 48-5-5 Lcd Screen Pcb 1
90 Plastic Flat Washer 2 48-5-6 MP3 Connect Wire 1
91 Wire Protector 1 48-5-7 Fan 1
92 Binder 1 48-5-8 Console Overlay 1
93 Strape 1 48-5-9 Tangible Keyboard Plastic Articals 1
94 Absorbe Cushion 1 48-5-10 Safety Key Plate 2
95 Silicon Bottle 1 48-5-11 Safety Key Thimble 1
96 Running Deck 1 48-5-12 Switch 1
97 Silicon Bottle(With Silicon Oil)-2 1 48-5-13 Safety Key Yellow Sticker 1
98 Adhesive Tape 1 48-5-14 Keyboard PCB 1
99 T Shape Wrench 1 48-5-15 Acrylic Touch Panel 1
100 Cross Open Wrench 4 48-6 Safety Key 1
101 Filter 17 48-7 Mp3 Connet Wire 1
102 Choke 1
103 Wire (Red) L=350Mm 1
104 Wire (Black) L=350Mm 1
105 Manual 1
Parts List
ZRK2/ZRK3 Treadmill
