Surface Speed Measurement
1. Move the Function Switch to the m/min. or ft/min. position.
2. Press the Measure Button and attach the surface speed test
wheel to the detector. Release the Measure Button when the
reading stabilizes.
Operation procedure for memory recall
1. Last value, Max. value and min. value are automatically stored
in memory.
2. To recall measurements saved in memory:
a. Push the Memory Call Button - To display the last
value ( LA and the last value will be displayed alternately).
b. Push the Memory Call Button again - To display
the maximum value (UP and the max. value will be
displayed alternately).
c. Push the Memory Call Button again - To display the
minimum value ( dn and the min. value will be displayed
alternately).
Max Value
Last Value
Min Value
Display
reading
Measuring Time
REED Instruments
1-877-849-2127 | info@reedinstruments.com | www.reedinstruments.com
