CREATE GROUP
Quickly create groups to further organize saved measurements. Groups are
automatically imported as tags in the ROCK Jobsite App.
LAYOUT GUIDE
Layout Guide shows multiples of the currently selected measurements on the E-Paper
Display. For example, if you select a 5 inch measurement, the T1 OLED blinks when you
reach 5, 10, 15, and 20 inches.
TOGGLE MEASURE FRONT/BACK
TOGGLE RELATIVE
The T1 can toggle between absolute measurements (how much of the tape blade is
extended) or relative measurements (user selects a "0" position at any point along the
tape measure).
The T1 can measure either from the front reference surface or from the back of the T1.
Measuring from the back allows the T1 to capture internal measurements effortlessly.
The T1 can display the center of a given measurement.
NOTE: To confirm that you are using the TOGGLE RELATIVE Quick Action, look for the
bracket on the left side of the OLED Display.
SHOW CENTER
NOTE: To confirm that you are using the SHOW CENTER Quick Action, look for the two
arrows in the middle of the OLED Display.
MAINTENANCE OF YOUR T1
NOTE: To confirm that you are using the MEASURE BACK Quick Action, look for the
bracket on the right side of the OLED Display. No bracket means you are in the default
mode using MEASURE FRONT Quick Action.
QUICK ACTIONS NAVIGATION
Press until you see the Quick Action Menu popup on
the OLED Display.
Press to make your selection and exit.
Using the arrows, highlight the quick action you
would like to use.
1.
2.
3.
NOTE: You can select multiple Quick Actions to use at once.
To turn off a quick action recently used, repeat steps 1-3.
WARNING: To reduce the risk of injury, the user must carefully read the T1 QUICK
START GUIDE. The person responsible for the T1 must ensure that all users understand
and comply with the instructions.
USER SAFETY
WARNING: Tape blade is electrically conductive. Do not use near bare wires.
INTENDED USE
DO NOT use under wet conditions or in the presence of flammable liquids or gases. DO
NOT replace any component of the T1 Tomahawk with a component that is not supplied
by REEKON Tools. DO NOT store or use the tool in locations where the temperature may
exceed 104 °F (40°C) or drop below 5°F (-15 °C). Best use in relative humidity conditions
of 8% to 80% non-condensing and altitudes no higher than 9,842ft (3,000 m). For best
performance operation of the device should take place in cool, dry conditions.
FCC COMPLIANCE
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. The device has been evaluated to meet general RF exposure requirement.
The device can be used with minimum distance 0mm between the radiator and your
body.
This radio transmitter has been approved by ISED Canada.
This Class B digital apparatus complies with Canadian standard ICES-003. This device
complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference, that may cause undesired operation
of the device.
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment.The device has been evaluated to meet general RF exposure requirement.
The device can be used with minimum distance 0mm between the radiator and your
body.
Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
ISED CANADA COMPLIANCE
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF.Cet
équipement doit être installé et utilisé avec une distance minimale de 0 mm entre le
radiateur et votre corps.
TECHNICAL ASSISTANCE & REPAIR
For questions about applications, technical support, repair or more
information, please see our website: https://www.reekon.tools
14.5”
TOGGLE
MB MF
QUICK ACTION OLED DISPLAY EXAMPLE
0”
10” 5”
QUICK ACTION OLED DISPLAY EXAMPLE
TOGGLE
REL
7.5”
15”
QUICK ACTION OLED DISPLAY EXAMPLE
SHOw
CENTER
15”0” 5” 10”
QUICK ACTION EXAMPLE
GUIDE
LAYOUT
QUICK ACTION E-PAPER DISPLAY
CREATE
GROUP
A
GROUP 2
CHARGING THE T1 BATTERY
The T1 is powered by the b1 rechargeable battery pack. To charge the battery of your T1,
slide up the Battery Lid located at the back of the device and connect a USB-C cable to a
source of at least 1 amp. The T1 takes approximately 2 hours to charge fully, depending
on the power source.
STEP 2: Slide the Battery
Lid down and leave space
to plug in USB-C cable into
the provided USB-C port.
STEP 1: Slide the Battery
Lid up and insert the
battery with the REEKON
logo facing right.
STEP 3: Once fully charged,
unplug the USB-C cable and
slide down the Battery Lid
to securely close it.
ROCK JOBSITE APP
With the ROCK Jobsite App, the T1 Tomahawk can send
measurements and other data over Bluetooth to any mobile
device. The ROCK Jobsite App allows for streamlined
measurement organization, sharing, calculations, and other
common jobsite functions, all in a centralized, easy to use,
mobile application.
Visit: https://reekon.xyz/rock to download the app.
(available on both iOS and Android)
There are several adjustable, repairable, and replaceable
components of the T1. This includes:
For complete, step-by-step instructions,
go to support.reekon.tools
- Tape Measure Blade
- Tape Measure Spring
- Display Protectors
- Reader Module
- Green Laser Module
