Refco GOBI - Installation

RightHanded
LeftHanded
Fig.1.Screw thebackplatetothewall
belowtheairhandlerandjust
overlappingtheoutlethole.Enlargethe
outletholeifnecessary.
3mm
Fig.2.Cutthedrainhoselevelwiththe
bottomofthebracket.
Fig.2
Fig.3.PlacetheGOBIpumponthe
mountingposts,feedthepowercable
throughtheairhandleroutletholeand
connectthedischargetube.
Fig.3
Fig.4.Slidethefilteroverthepumpinlet
tubeandfitthecondensatecollection
trayontothebackplate.
Fig.4
Fig.5.Slideonthecoverandsnapinto
place.
Fig.5
Installation
TheGOBIcanbeinstalledontheleftorrighthandsideoftheairhandler.
Thefollowinginstallationinstructionsrefertoarighthandedinstallation.Forlefthanded
installationsswapthepositionsofthepumpandcondensatecollectiontrayasshown
below.
GB
3
Fig.1
3mm
