Refco GOBI User Manual

WiringConnections
Connecttheground,liveandneutralwirefromthesupplycableoftheGOBIpumpto
thesupplyterminals(seeFig.6)
Thisproductmustbeconnectedusingaswitchwithcontactseparationinallpolesthat
providefulldisconnectionfromthepowersupplyunderover-voltagecategoriesIII. A
fusenontimedelay(rated250V1A),shallbefittedintotheline,supplyside(see ).Fig.6
AlarmContacts
VoltFreeBreakOnFaultconnectionisrated5
amps1250VA.Itmaybenecessarytousea
contactoriftheairhandlersupplyistobeswitched.
CableConnections
1 GREEN/ YELLOW EARTH E
2 BLACK LIVE L
3 WHITE NEUTRAL N
4 VIOLET Alarmcontact
5 VIOLET Alarmcontact
WireColour Connect Symbol
E
L N
POWERSUPPLY
CONTROL
CIRCUIT
1A
FUSE
1 2
3 4 5
Fig.6
Set-up&Test
Warning .1. -thepumpisliveduringtesting
2. RemovetheGOBIcover.
3. Halffillthecondensatecollectiontraywith
cleantapwater- Thepumpwillstartonlow
power.Itmaybenoisywhilstairispurged
fromthesystem.
4. Continuetoaddwateruntilthesensorisfully
submerged- Thepumpwillswitchtofull
powerandthealarmcontactswillopen.
5. AllowtheGOBItoremovethewaterfrom
thecollectiontray- Thepumpwillstopand
thealarmcontactswillclose.
6.Re-fittheGOBIcover.
CoilCleaning
Donotallowthepumptocollector
operatewithcleaningchemicalsinthe
system.
Disconnect ALL powersupplies.1.
2. Removeair-handlercover,GOBIcover
andcondensatecollectiontray.
3. Followmanufacturersinstructionsbut
collectchemicalsinaseparatecontainer.
4. Flushthesystemwithcleanwater.
5. Re-fitcondensatecollectiontray,GOBI
coverandair-handlercover.
4
GB
