Piping
Run discharge tubing to a suitable drain where it is unlikely to freeze during
operation. The highest point of the run must be less than 15m / 49ft above
the pump and not more than 0.3m / 1ft below to avoid siphoning (fig. 7). Ma-
ximum tube length is 100m / 330ft. Take care not to pinch or kink the tubing.
Secure or support the discharge tube to reduce noise. Push the rubber inlet
connector onto the drain hose (fig. 3) or collection tray stub. Secure with the
cable ties provided. Bend into position the breather support wire so tube
end is above collection tray if possible (fig.8).
Wiring
WARNING! SWITCH OFF ALL SUPPLIES AT THE FUSE BOX BEFORE MA-
KING CONNECTIONS TO THIS PUMP.
This pump requires an Earth/Ground connection. The installation must pro-
vide a suitable means for electrical disconnection (fig.3).
Fuse Protection Required
Europe: 5 A max.
European Cable: 0.75mm²
USA Factory fitted cable is 18 AWG for equipment
internal wiring only.
Refer to National and Local Electrical Codes for fusing and disconnection
requirements.
EUROPEAN Cable Colour Coding
BROWN L LIVE PHASE
BLUE N NEUTRAL
GREEN/YELLOW E EARTH
BLACK ALARM RELAY
GREY ALARM RELAY
USA Cable Colour Coding
BLACK L1 LIVE PHASE
WHITE L2 NEUTRAL
GREEN GROUND
ORANGE ALARM RELAY
RED ALARM RELAY
Alarm Relay
The alarm relay is energised to make continuity during normal operating
conditions (break on fault).
Inspection and Maintenance
Inspect the filter for sediment and debris. When handling pump during in-
spection and maintenance, keep pump assembly reasonably upright and
level to prevent any water spills from entering the pump. In some instal-
lations it may be possible to service the pump while still attached to the
equipment. If necessary support the pump assembly to prevent excessive
strain on cables and connections. If cleaning is required, disconnect the fil-
ter housing by rotating 80° counter clockwise and carefully separate (fig.9).
Do not use detergents in servicing this product. Using a small tool carefully
lift the filter out of its location and rinse under a tap with clean water. If the
O ring is disturbed, clean O ring and mating surfaces and re-seat (fig.10). In-
