Audio Inputs
(2)
Level
-30dBu minimum
Impedance
stereo/50
kQ
unbalanced
mono/25
kQ
unbalanced
Audio
Outputs
(2)
Level
-2dBu
nominal
+8dBu
maximum
Impedance
75Q.
unbalanced
Muting
reduces
transients during
power
on/off
Footswitch
Connectors
T/R/S
phone jack
for
bypass
and
register
step
MIDI
Connectors
5-pin
DIN
connectors
for MIDI IN
and
MIDI
OUT or
THRU
(selectable via internal
jumper)
Frequency response
Wet
20Hz-15kHz,
-r1dB
to -3dB
Dry 20Hz-20kHz,
±0.5dB
THD+N
Wet
<0.05%
@
1kHz
Dry
<0.025%
@
1kHz
Dynamic
Range
85dB, typical,
20Hz-20kHz
bandwidth
Conversion
16 bit
linear PCM
encoding; 31.25kHz sampling
rate
Power
Requirements
9VAC, 1
A wail transformer
provided
Dimensions
19"Wx
1.75"Hx4"D
(483
X 45 X 102mm)
Weight
2
lbs
1
1
oz
(1
.22 kg)
Environment
Operating
Temperature
32°
to
104°F
(0°
to
40°
C)
Storage
-20°
to
1
70°F
(-30°
to
75°
C)
Relative
Humidity
95%
non-condensing
