49
© reex.de | 02.2021 | 9130573 | Reex Storatherm Aqua
I II IIl
TYPE
(G)
R mm
(A)
R mm
(J)
mm DN/LK
(D/E)
mm
(C)
R mm
(F)
R mm
(B)
R mm
(H)
mm
AF 150 / 1M_A 1" 90 1" 994 325 110/150 339/511 1" 637 1" 255 ¾ " 737
687
AF 200 / 1M_A 1" 90 1" 1194 325
110/150
339/585 1" 737 1" 255 ¾ " 868
787
AF 300 / 1M_A 1" 55 1" 1229 275 110/150 307/549 1"
721 1" 221 ¾ " 921
756
AF 400 / 1M_A 1" 55 1" 1526 276 110/150 369/684 1" 909 1" 221 ¾ " 1112
958
AF 500 / 1M_A 1" 55 1" 1856 276 110/150 389/696 1" 966 1" 221 ¾ " 1265
1041
AB 100 / 1_C ¾ " 55 ¾ " 740 248 --- 428 1" 523 1" 193 ¾ " 605
---
AB 150 / 1_B ¾ "
55
¾ " 1110 248 110/150 458 1" 598 1" 193 ¾ " 734
---
AB 200 / 1_C ¾ " 55 ¾ " 1366 246 110/150 506 1" 686 1" 191 ¾ " 899
---
AB 300 / 1_B 1" 55 1" 1229 276 110/150 549 1" 721 1" 221 ¾ " 921
---
AB 400 / 1_C 1" 55 1" 1526 275 110/150 684 1" 909 1" 221 ¾ " 1112
---
AB 500 / 1_C 1" 55 1" 1853 275 110/150 695 1" 965 1" 220 ¾ " 1264
---
AF 200 / 1M_C ¾ " 55 ¾ " 1366 246
110/150
282/506
1" 686 1" 191 ¾ " 899
743
AF 400 / 1M_C 1" 55 1" 1526 275 110/150 369/684 1" 909 1" 221 ¾ " 1112
957
AF 500 / 1M_C 1" 55 1" 1853 275 110/150 381/695 1" 965 1" 220 ¾ " 1264
1040
AF 750 / 1_C 1 ¼ " 99 1 ¼ " 1886 378 180/225 1079 1 ¼ " 1314 1 ¼ " 288 ¾ " 1417
---
AF 1000 / 1_C 1 ¼ " 103 1 ¼ " 1900 386 180/225 1087 1 ¼ " 1324 1 ¼ " 296 ¾ " 1489
---
AF 1500 / 1_C 2" 105 2" 2048 412 180/225 1140 1 ¼ " 1543 1 ¼ " 333 1 ¼ " 1660
---
AF 2000 / 1_C 2" 118 2" 1937 443 180/225 1175 1 ¼ " 1568 1 ¼ " 360 1 ¼ " 1670
---
AF 3000 / 1_C 2" 156 2" 2691 481 180/225 1470 1 ¼ " 1930 1 ¼ " 396 1 ¼ " 2406
---
AF 150 / 1M_B ¾ " 55 ¾ " 1110 248 110/150 458 1" 598 1" 193 ¾ " 734 ---
AF 200 / 1M_B ¾ " 55 ¾ " 1366 246 110/150 282/506 1" 686 1" 191 ¾ " 899
743
AF 300 / 1M_B 1" 55 1" 1229 276 110/150 307/549 1" 721 1" 221 ¾ " 921
755
AF 400 / 1M_B 1" 55 1" 1526 275 110/150 369/684 1" 909 1" 221 ¾ " 1112
957
AF 500 / 1M_B 1" 55 1" 1853 275 110/150 381/695 1" 965 1" 220 ¾ " 1264
1040
AH 300 / 1_B 1" 55 1" 1229 275 110/150 466/874 1 ¼ " 784 1 ¼ " 220 ¾ " 544
830
AH 400 / 1_B 1" 55 1" 1526 275 110/150 592/1190 1 ¼ "
1100 1 ¼ " 220 ¾ " 666
1140
AH 500 / 1_B 1" 55 1" 1856 275 110/150 699/1369 1 ¼ "
1279 1 ¼ " 220 ¾ " 1035
1319
AH 400 / 1_C 1" 55 1" 1526 275 110/150 592/1190 1 ¼ "
1100 1 ¼ " 220 ¾ " 666
1140
AH 500 / 1_C 1" 55 1" 1856 275 110/150 699/1369 1 ¼ "
1279 1 ¼ " 220 ¾ " 1035
1319
AH 750 / 1_C 1 ¼ " 99 1 ¼ " 1887 378 180/225
1060-1510
510-960
1 ¼ "
1260 1 ¼ " 287 ¾ " 990
1490
AH 1000 / 1_C 1 ¼ " 103 1 ¼ " 1905 387 180/225
1060-1510
510-960
1 ¼ "
1360 1 ¼ " 297 ¾ " 1045
1545
