COAX MODE
Connect an external device such as an audio player or TV to the SB300 with an RCA cable to play music from
your external device via cable. Audio player or TV set are not included.
1. Switch on the SB300.
2. Connect your external device to the COAX input of the SB300 using an RCA cable.
3. Press the Mode button to switch to AUX mode. An announcement says the mode "Coaxial mode".
4. Start playback on your external device.
5. You control the playback with the external device.
6. You control the volume on your external device and the SB300.
Note:
 If the basic volume of the SB300 or your external device is set too low, you may not be able to hear
any sound from the SB300. In this case, increase the volume.
TECHNICAL INFORMATION
GENERAL
Power supply unit
USB Type-C: DC 5V / 1000mA
Maximum power consumption
Max. 5W
Standby power consumption
< 0,5W
Battery type
Built-in rechargeable lithium battery
(2200mAh / 3.7V)
AUX-IN connection
3.5mm AUX socket
COAX connection
Cinch socket (digital input)
USB connection
Type-A: DC 5V / 500mA
Max. 32GB / FAT32 (MP3, WAV)
TF slot
Micro SD card slot
Max. 32GB / FAT32 (MP3, WAV)
Working temperature
-10°C - +60°C
Storage temperature
-40°C - +85°C
Max. Music power
Max. 2x 40W
BLUETOOTH
Version / Frequency
V 5.0 / 2,4GHz
Range
Approx. 10 metres (line of sight)
Profiles
RF.5.2 / BB.5.2 / LL.5.2 / LMP.5.2 / RFPHY.5.2 /
SDP.5.2 / SM.5.2 / GAP.5.2 / L2CAP.5.2 / A2DP.1.3.2
/ AVCTP.1.4.1 / AVDTP.1.3.6 / AVRCP.1.6.2 /
GAVDP.1.3.1 / HFP.1.7.2 / HSP.1.2.10 / HID.1.0.14 /
IOPT.4.0.1 / RFCOMM.1.2.2 / SPP.1.2.4 / BAS.1.0.3
Dimensions
Dimensions (L / D / H) in mm
780 x 62 x 62 mm
Weight
0,95 Kg
Design and specifications are subject to change without notice.
