124
AUTOMATIC
CHARGING
RELAY
POWER
STEERING
BREAKER
DASH MAIN
BREAKER
HOUSE
BATTERY
SWITCH
DC DISTRIBUTION
PANEL
POWER
INLET
PLUG
GFCI
WARNING
LABEL
WINDLASS-
BREAKER
AUX. CHARGE
BREAKER-
EARLIER
LX6 BATTERY MANAGEMENT PANEL
THRUSTER-
SWITCH
THRUSTER-
FUSE
MID BILGE
PUMP
SWITCH
POWERTOWER
ACTUATOR
CONTROL BOX
ENGINE
BATTERY
SWITCH
LAZARETTE
ACTUATOR
CONTROL BOX
Note that select items mentioned above or displayed
are optional equipment and may not be installed on
your vessel. The battery management panel is found
under the starboard cockpit seat cushion.
GALVANIC
ISOLATOR
CAUTION
BATTERY
CHARGER
20 AMP OUTPUT
Since the battery management panel is the
“heartbeat” of onboard components functions of
each device will be found in the next pages. Refer to
the owner’s information packet for more information.
STABILIZER/
SEAKEEPER
BREAKER
