195
Waste Tank (Typical Electric Toilet System)
Overview
The waste water system on your vessel is located in
the starboard bilge. The system features a pump-out
fi tting mounted on the deck labeled “waste”.
A monitor panel shared with the fresh water system
displays the waste tank level when activated. Press
the lower portion of the switch and read the gauge
waste level. The waste tank can be pumped out at
select marine facilities. Normally a hose is attached
to the deck waste fi tting and the tank waste is then
pumped into a dock side facility storage container.
After the pump out procedure use a garden hose and
nozzle to rinse the pump out hose before recapping
the waste fi tting. This will assist in reducing residue
build up in the inside of the waste hose.
Overboard Discharge System
HOSE TO SEACOCK
SEACOCK
OVERBOARD DISCHARGE
PUMP/MACERATOR
