94
PORT AFT
BAG PUMP
STARBOARD
AFT BAG
PUMP
CENTER
BAG PUMP
STRAIGHT
UP-OPEN
POSITION
PORT & STARBOARD
AFT BAG SEACOCK
CENTER BAG
SEACOCK
BILGE PUMP
AUTOMATIC
SWITCH
BILGE
PUMP
Notes Regarding Wake Surf Pump System
1. In freezing climates contact your closest Regal
dealer for winterizing the wake surf system along
with the entire propulsion system. Dealers have the
special tools and latest knowledge regarding these
systems. Regal is not responsible for any damage
due to improper winterization.
2. Periodically check the entire surf pump and bal-
last bag system for leaks and abrasions.
3. Never store anything in the bag compartments.
Bag could fail due to heavy and/or sharp objects.
4. Periodically check all hoses and hose clamps are
securely fastened. Do not operate the surf pumps
out of water as pump/impeller damage will occur.
5. If leaving the vessel in the water for extended
periods turn the surf pump sea cocks to the “off”
position (90 degrees to the straight up position)
and leave a note to yourself on the dash to turn sea
cocks on before using the surf system again. Also,
remove keys from the ignition switch.
BOW
Typical Surf Boat Pump System
Note: Equipment specifi cation, location, and operation changes may occur over the vessel production life.
