4-3
No Diving or Jumping. Observe all Safety Rules
C. INSTALLATION OF TOP LEDGE AND LEDGE COVERS
GENERAL INSTRUCTIONS - ROUND POOLS
ASSEMBLING THE POOL FRAME
Secon
4
1. Install top ledge
NOTE: Depending on your pool model you may have
steel or resin top ledge.
a. Place top ledges on the wall. Align the holes on the
top ledges with those on the top plates. Make sure
the space left between each top ledge is uniform
all around and that the space in question can be
covered by a ledge cover. Attach the top ledges to
the top plates using screws.
Steel Top Ledge on Steel Top Plate: Image 8 (V12x34)
Resin Top Ledge on Steel Top Plate: Image 9(V12x34)
Resin Top Ledge on Resin Top Plate:
Image 10(VHL12x114S & FW10x34S)
Important Note:
We suggest that you install all the top ledges on the
wall before attaching them.
8
9
10
