05 Operation via integrated web pages
The integrated web pages can be used as an alterna-
tive to the NEA SMART 2.0 app via the browser of a
smartphone, tablet or PC.
The IP address of the device is 192.168.0.2.
Via the web pages, you can:
▪ Assign names to the rooms and set the desired
temperatures
▪ Create timer programmes for the desired tempera-
tures and assign them to the rooms
▪ Select the operating modes “normal mode”’ and
“reduced mode” for all rooms or individual rooms
▪ Use the holiday function
▪ Switch between heating mode and cooling mode
To use the web pages, a direct connection must be
established between the device (smartphone, tablet,
PC) and the NEA SMART 2.0 Base. The web pages can
only be accessed with one device at a time.
It is not possible to use the app and the integrated
web pages at the same time.
Setting up the base for using the web pages
For systems in which there is more than one base,
communication always takes place via the “master”
Base. Ask your installer which Base has been estab-
lished as the master.
Activating communication
When the system is delivered, the communication
functions of the base station via wireless LAN and LAN
are switched o.
The NEA SMART 2.0 Base may only be handled if the
cover is in place on the NEA SMART 2.0 Base. If this is
not the case, the installer has to be called.
1
Press both arrow buttons at the same time
for > 3 seconds
The WIFI/LAN LED and/or the AP LED will begin to
flash.
Confirm by briefly pressing the OK button. The current
status of the transmitting function is displayed.
OK ><
> 3 sec
RZ12 COOL ZBUS1
DI4 WIFI/LAN
RZ11
DI3 AP
WIFI/LAN AP
WIFI/LAN AP
WIFI/LAN AP
WIFI and LAN o
Cloud Mode
Access Point Mode
16 End user manual
