4 OPERATION
4.1 Overview and display
Housing
Control knob
Fig. 4-1 Front view of Nea Smart room control unit
4.2 Commissioning (incl. pairing)
1. Remove the control knob.
2. Activate the pairing function at the base station for the desired
heating zone (see manual base station Nea Smart 24 V).
3. Press the pairing button (see figure below) briefly in order to
activate the pairing function of the room control unit.
The base station and the room control unit are connected to each
other.
Fig. 4-2 Pairing button under the control knob
4.3 Operation
Set the target temperature by rotating the control knob.
Fig. 4-3 Selecting the target temperature
4.4 Connection test
Press the pairing knob briefly in order to activate the connection test.
At the base station, the heating zone connected to this room control
unit is changed for 1 minute, in other words switched on or o
depending on the previous operating status.
7
