Take your caravan or trailer outdoors. We
suggest you choose a large area with sufficient
safety margin to people and objects until you
have enough experience in operating the
MoveControl.
Activate the MoveControl by means of a
double click
on the I/O key at the remote
control (ON
) - the LED will be lighting.
Check the function of the MoveControl by
pushing the buttons on the remote
control.
B2 Turn ON MoveControl
+
B3 Engaging the friction rollers:
First, travel the friction rollers to the tyres using
the remote control.
Simultaneously
push the two arrow keys on the
remote control and keep them pressed until the
driving rollers are completely extended:
As soon as the final position is reached, the
MotorDrive will be switched-off automatically.
Only in this position the moving process is
allowed to!
Undo the handbrake of your caravan.
Now you can execute the
movements according to the
symbols shown on the remote
control. The vehicle only
moves as long as you keep the
buttons pushed down.
B4 Moving
If no key should be actuated within 20 seconds,
the remote control will be switched-off
automatically and must be switched-on again.
GB8
6. Startup / Operation d
Turn ON the isolation switch.
Make sure that both drive units have
been disconnected from the vehicle tyres.
B1 Turn ON System
Caution: If the driving rollers will not turn, the
reset procedure must be effected at the base
station or a resynchronisation of the remote
control and the receiving unit (base station) must
be effected.
Be carefull that no one is in the
moving area while mamoeuvring the
caravan!
Also check on the side of the
caravan which turned away from
you.
Keep a safe distance during moving.
Always keep sufficient distance of
the friction rollers after maintenance
or cleaning.
Switching plant absolutely current-
freely and safeguarding vehicle
against roll away at works in the
area of the friction rollers.
English
