1 Volume Control for HI/LOW INPUT: Use to adjust output when using either HIGH-LEVEL or LOW-LEVEL
input. Do not use both simultaneously.
2 Volume Control for .1/LFE INPUT: Use to adjust output level when using .1/LFE input from a 5.1 amplifier
or processor.
3 Crossover Control: Used to select crossover frequency. Variable between 30Hz and 120Hz.
4 LOW-LEVEL INPUT: Used to connect LOW-LEVEL to the output of a preamplifier, integrated
amplifier or receiver ONLY when HIGH-LEVEL INPUT cannot be properly connected. (For home
cinema, use.1/LFE INPUT).
5 .1/LFE INPUT: Used to connect to the .1/LFE output from a 5.1 amplifier of processor. Should be
used in conjunction with REL HIGH-LEVEL connection for the ultimate theater experience.
6 Phase Switch: Used to set phase 0-180 degrees.
7 Power Mode Switch: Used to set power mode. Set to “ENERGY SAVER” to enable automatic standby
function or to “ALWAYS ON” to disable standby function.
8 HIGH-LEVEL INPUT (Neutrik® Speakon® Socket): Use to connect HIGH-LEVEL to the main
front amplifier speaker terminals.
9 Power ON/OFF Switch: Use to turn unit on or off.
10 IEC Mains Socket: Fused mains (AC) input socket that accepts a detachable power cord.
6
