Model A-2 Pressure Maintenance Device
P/N 6304000135, (All steel pipe fittings are galvanized)
Item
No.
Part No. Description
No.
Req’d
1
2
3
4
5
6
7
8
9
10
11
12
13
14
98681630
98727606
96816902
98840172
98840108
98815201
96606616
98543234
98543226
98174404
98543227
96606608
98614403
98543231
Regulator, 5-100 psi
Strainer, ¼” NPT, 90
Check Valve, ¼”
Globe Valve, ¼”
Ball Valve, ¾”
Union, ¼”
Tee, ¾” x ¾” x ¼”
Nipple, ¾” x 3½”
Nipple, ¼” x 1½”
Elbow, ¼”
Nipple, ¼” x Close
Tee, ¼”
Plug, ¼”
Nipple, 3/4 x 3”
1
1
1
2
1
1
2
1
5
1
2
1
1
1
Model B-1 Pressure Maintenance Device
P/N 6304010100, (All steel pipe fittings are galvanized)
Item
No.
Part No. Description
No.
Req’d
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
98728801
98727607
96816902
98840172
98840108
98815201
96606616
98543232
98543226
96606608
98750004
98543227
98523100
98768000
98085630
98048034
98614403
98543231
Pressure Switch,
3
/
8
” NPT
Strainer, ¼”, 30 Mesh
Check Valve, ¼”
Globe Valve, ¼”
Ball Valve, ¾”
Union, ¼”
Tee, ¾” x ¾” x ¼”
Nipple, ¾” x 2 ”
Nipple, ¼” x 1½”
Tee, ¼”
Cross, ¼”
Nipple, ¼” x Close
Restriction Nipple, ¼”
Copper Tubing, ¼” O.D.
Comp. Fitting, ¼” x ¼”
Reducer Bushing
3
/
8
” x ¼”
Plug, ¼”
Nipple, ¾” x 3”
1
1
1
2
1
1
2
1
5
1
1
1
1
1
1
1
1
1
Figure 2
Figure 1
