Reliable H Deluge Riser - Page 4

4.
1½” DELUGE RISER ASSEMBLY, P/N 6503003001 and P/N 6503003007
(*)
, PARTS LIST
ITEM
NO.
PART NO. DESCRIPTION
Number
REQ’D
1 6201201500 Valve, Butterball, 1½” (BB-SCS02) 1
2 6201001500 Valve, Butterball, 1½” (BB-SC100) 1
3 98840170 Valve, Globe, ¾” 1
4 6871080000 Valve, Solenoid, 2” 1
5 98840160 Valve, Gauge, 3-Way, ¼” 2
6 98248001 Gauge, Pressure, Water 2
7 98543230 Nipple, ½” X 3” Lg. (Galv.) 1
8 96606607 Tee, ½” X ½” X ¼” (Galv.) 1
9 96606601 Tee, ¾” (Galv.) 1
10 96606622 Tee, 1½” X ½” X 1½” (Galv.) 1
11 96606621 Tee, 1½” X ¾” X 1½” (Galv.) 1
12 96606625 Tee, 2” X 1½’ X 1½” (Galv.) 1
13 98543238 Nipple, 2” X Close (Galv.) 1
14 98543275 Nipple, 1½” X 2½” Lg. (Galv.) 1
15 98543274 Nipple, 1½” (thd X grv) X 4” Lg. (Galv.) 2
16 98543276 Nipple, 1½” X 3½” Lg. (Galv.) 2
17 98543288 Nipple, 1½” X 9½” Lg. (Galv.) 1
18 98543290 Nipple, ¾” X 8½” Lg. (Galv.) 1
19 98543279 Nipple, ¾” X Close (Galv.) 5
20 98543212 Nipple, ½” X Close (Galv.) 4
21 98543227 Nipple, ¼” X Close (Galv.) 2
22 95306209 Clamping Ring (OETIKER #515) 2
23 95306210 Clamping Ring (OETIKER #575) 2
24 95106905 Plate, Base 1
25 98543204 Nipple, ½” X 6” Lg. (Galv.) 1
26 94616910 Nameplate, 1½” Deluge System 1
27 94606910 Name Plate, Manual Emergency Station 1
28
6999991339 Switch, Pressure (Eps10-1)
1
6999992366 Switch, Pressure (Epsa10-2)
(*)
30 98614403 Plug, ¼” (Galv.) 2
31 98614401 Plug, ¾” (Galv.) 1
32 98750025 Cross, 2” X 1½” (Zinc Coated) 1
33 98085680 Coupling, 1½” Grooved With ¾” npt Outlet 1
35 95200002 Plug, 1½” (Galv.) 1
36 95106904 Plate, Base, Manual Emer. Station 1
37 98840109 Valve, Ball ½” 1
38 78653100 Valve, Ball Drip, Automatic Drain 1
39 75000075 Cup, Priming, ¾” 1
40 98174400 Elbow, ½” Street (Galv.) 2
41 98048022 Bushing, ¾” X ½” (Galv.) 1
42 98048025 Bushing, ¾” X ¼” (Galv.) 1
43 98174402 Elbow, ¾” (Galv.) 1
44 98174401 Elbow, ½” (Galv.) 1
45 98761651 Tee, ½” (Galv.) 2
46 98815200 Union, ½” (Galv.) 1
47 98750005 Cross, ¾” (Galv.) 1
48 98543216 Nipple, ½” X 3½” Lg. (Galv.) 1
49 98543228 Nipple, ½” X 4½” Lg. (Galv.) 1
50 98543209 Nipple, ½” X 2” Lg. (Galv.) 1
51 98840180 Valve, Check, ¾” 1
52 98840181 Valve, Check, ½” 1
53 98085668 Couping, Reducer 2” X 1½” (Galv.) 1
(*)
Canadian Type
