Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
R150,R250,R350,R450,
CARBON FILM RESISTOR(51K OHM,1/6W,J,T-26) 412-KM300-116 4
R119,R219,R319,R419,R90
1,R902,
CARBON FILM RESISTOR(3.9K OHM,1/6W,J,T-26) 412-KT300-107 6
R884,R885,R886,R887,R88
8,R889,R890,R891,
CARBON FILM RESISTOR(56 OHM,1/6W,J,T-26) 412-KT346-113 8
R897, CARBON FILM RESISTOR(1 OHM,1/6W,J,T-26) 412-RC6-142 1
R146,R246,R346,R446,
CARBON FILM RESISTOR(20K OHM,1/6W,J,T-26) 412-STR880-482 4
DSP ADAPTOR PCB ASS'Y 704-U40-6443 1
W405,
3P2.5 CONNECTOR WIRE(UL1007#26 L=30mm)(Cd,Pb)
404-40DSP-1952 1
W07,W205,W305, 4P2.5 CONNECTOR WIRE(UL1007#26 L=30mm) 404-40DSP-1953 3
W105, 5P2.5 CONNECTOR WIRE(UL1007#26 L=30mm) 404-40DSP-1954 1
W906, 6P2.5 CONNECTOR WIRE(UL1007#26 L=30mm) 404-40DSP-1955 1
W905, 7P2.5 CONNECTOR WIRE(UL1007#26 L=30mm) 404-40DSP-1956 1
W09, 10P2.5 CONNECTOR WIRE(UL1007#26 L=30mm) 404-40DSP-1958 1
CN10A,CN11A, 10P FFC CONNECTOR(SMD) 404-CDMIX2-1142 2
IC803, IC SOCKET(PLCC-DIP-32P) 404-CDN88-016 1
W910,
3P2.5 CONNECTOR WIRE(L=80mm,AWM2877 AWG26)
404-HPM11-1593 1
CN08, 5P SOCKET(CKM2501-WV-5P,180° WHITE) 404-HV3500K-622A 1
W104,
3P 2.5 CONNECTOR WIRE(L=250mm,AWM2877,AWG26)
404-RMX20-1869 1
W601,
4P 2.5CONNECTOR WIRE(L=70mm,AWM2877,AWG26)
404-RMX40-1985 1
C823,
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING 5*7,MINI)(Cd,Pb,Hg,Cr)
413-HMA2200-5017 1
C873,
ELEC. CAPACITOR(220uF/10V,M,105℃,TAPING 6.3*7,MINI)
413-HT801K-192 1
L801,L802,L804,L806,L807,
BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 5
X801, CRYSTAL(XTAL 16.9344MHz,32PF,CYLINDER TYPE) 427-KC710-019 1
SPACER SUPPORT(H-25) 504-RMX50BPM-163 6
PLASTIC SCREW(S-306-N66) 602-SPANDMK2-536 6
STANNUM 611-3113-002 0.75
STANNUM 611-3113-002A 2.25
IC803, DSP IC ASS'Y 704-D40-5285C 1
IC(AT29LV010A-15JC,PLCC-32) 417-HDJ2000-413C 0
IC(A290011TL-70F) 417-HDJ2000-413E 1
IC803, DSP IC ASS'Y(CHECK SUM:707A/3.0) 704-D40-5285D 0
IC(AT29C010A-90JU,PLCC-32) 417-HDJ2000-413D 1
R604,R612, CHIP RESISTOR(180K OHM,1/8W, 0805,J,TP,150V) 412-CDMIX2-506 2
R757,R758, CHIP RESISTOR( 3.9K OHM,1/8W, 0805,J,TP 150V) 412-DRM120-568 2
R821,R822,R832, CHIP RESISTOR(100 OHM,1/8W,J,0805,150V) 412-DV330-304 3
R147,R148,R155,R156,R16
5,R166,R247,R248,R255,R2
56,R265,R266,R347,R348,R
355,R356,R365,R366,R447,
R448,R455,R456,R465,R46
6,R605,R606,R613,R614,R6
25,R626,R641,R642,R697,R
698,R713,R714,R719,R720,
R801,R803,R809,R810,R81
9,R833,R834,R835,R836,R8
37,
CHIP RESISTOR(10K OHM,1/8W,0805,J,TP 150V) 412-DV330-306 48
20
