Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
C155,C156,C255,C256,C35
5,C356,C455,C456,C504,C6
93,C694,
ELEC. CAPACITOR(1uF/50V,M,105℃,TAPING 4*7,MINI)
413-SPPW3-234 11
C221,C149,C222,C321,C32
2,C421,C422,C508,C697,C6
98,C121,C122,C884,
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING 4*7,MINI)(Cd,Pb,Hg,Cr)
413-SPPW3-235 13
C137,C138,C237,C238,C33
7,C437,C438,C667,C668,C6
69,C670,C338,
ELEC. CAPACITOR(22uF/16V,M,105℃,TAPING 4*7,MINI)
413-SPPW3-236 12
C506,
ELEC. CAPACITOR(47uF/25V,M,105℃,TAPING 6.3*7,MINI)(Cd,Pb,Hg,Cr)
413-SPPW3-237 1
Q802,Q803,Q804,Q805,Q80
6,Q807,Q808,Q809,Q810,Q
812,Q813,Q814,Q815,Q816,
Q817,Q818,Q819,
TRANSISTOR(TR 2SA933AS(R) TAPING) 416-3113-008 17
MIXER PCB(ETL-XPC-204,94V0,339*320*1.6t) 405-40USB-1768A 1
R117,R118,R217,R218,R31
7,R318,R417,R418,R513,
CARBON FILM RESISTOR(100K OHM,1/6W,J,T-26) 412-3113-047 9
R505,R127,R128,R135,R13
6,R227,R228,R235,R236,R3
27,R328,R335,R336,R427,R
428,R435,R436,R509,R511,
CARBON FILM RESISTOR(2.2K OHM,1/6W,J,T-26) 412-3113-048 19
R139,R239,R339,R439,R73
3,R140,R240,R340,R440,R5
18,R734,
CARBON FILM RESISTOR(15K OHM,1/6W,J,T-26) 412-3113-053 11
R143,R243,R343,R443,R519,
CARBON FILM RESISTOR((27K OHM,1/6W,J,T-26) 412-3113-054 5
R133,R233,R333,R433,R51
2,R514,R862,
CARBON FILM RESISTOR(4.7K OHM,1/6W,J,T-26) 412-3113-055 7
R578,R893,R895,R896,R894,
CARBON FILM RESISTOR(470 OHM,1/6W,J,T-26) 412-3113-056 5
R748, CARBON FILM RESISTOR((3.3K OHM,1/6W,J,T-26) 412-3113-057 1
R507,R508,R752,R751,
CARBON FILM RESISTOR(100 OHM,1/6W,J,T-26) 412-3113-060 4
R665,R666,R685,R686,
CARBON FILM RESISTOR((47K OHM,1/6W,J,T-26) 412-3113-063 4
R657,R658,R659,R660,R66
1,R662,R677,R678,R679,R6
80,R681,R682,R738,R850,R
853,R903,R904,R907,R908,
R736,
CARBON FILM RESISTOR(10K OHM,1/6W,J,T-26) 412-3113-068 20
R743,R744, CARBON FILM RESISTOR(6.8K OHM,1/6W,J,T-26) 412-3113-069 2
R138,R238,R338,R438,R516,
CARBON FILM RESISTOR(56K OHM,1/6W,J,T-26) 412-3113-071 5
R510, CARBON FILM RESISTOR(270K OHM,1/6W,J,T-26) 412-3113-077 1
R149,R249,R349,R449,R87
5,R876,R877,
CARBON FILM RESISTOR(1K OHM,1/6W,J,T-26) 412-3113-078 7
R767,R688,R669,R687,R68
9,R766,
CARBON FILM RESISTOR(4.3K OHM,1/6W,J,T-26) 412-HC1421FR-245 6
R676,R652,R653,R654,R65
5,R656,R672,R673,R674,R6
75,
CARBON FILM RESISTOR(2K OHM,1/6W,J,T-26) 412-HC1421FR-246 10
R141,R142,R241,R242,R34
1,R342,R441,R442,R517,
CARBON FILM RESISTOR(7.5K OHM,1/6W,J,T-26) 412-HDJ2400-376 9
19
