Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
R651,R671,R864,R869,R87
3,
CHIP RESISTOR ( 2K OHM,1/8W,0805,J,TP 150V ) 412-STR880-479 5
R502,R571,R572,R573,R57
4,R575,R576,
CHIP RESISTOR (470 OHM,1/8W, 0805,J,TP,150V) 412-VCDG3-395 7
C689,C690, CHIP CAPACITOR(22pF/50V,J,0805 TYPE,NPO) 413-CDN88-080 2
C159,C160,C259,C260,C35
9,C360,C459,C460,C507,
CHIP CAPACITOR(100pF/50V,J,0805 TYPE,NPO) 413-DV330-310 9
C875,C876,C887,C889,C891,
CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311 5
C874,C883,C885,C886,
CHIP CAPACITOR(0.01uF/50V,K,0805 TYPE,X7R) 413-DV330-312 4
C134,C234,C334,C434,C66
5,C666,C892,
CHIP CAPACITOR(0.1uF/ 50V,Z,0805 TYPE,Y5V) 413-DV330-313 7
C691,C692, CHIP CAPACITOR(0.027uF/50V,K,0805 TYPE,X7R) 413-DV330-320 2
C879,C880, CHIP CAPACITOR(12pF/50V,J,0805 TYPE,NPO) 413-DV330-326 2
C701,C702, CHIP CAPACITOR(1500pF/50V,K,0805 TYPE,X7R) 413-PRODJ2-465 2
C135,C136,C235,C236,C33
5,C336,C435,C436,C503,C5
14,C661,C662,C663,C664,C
699,C700,C901,C902,C905,
C906,
CHIP CAPACITOR(68pF/50V,J,0805 TYPE,NPO) 413-QMX2-133 20
D801,
SWITCHING DIODE(ISS355,TE-17,100mA,90V,UMD2)
414-CD1000-075 1
Q821,Q822,Q826, TRANSISTOR(TR DTC124EKAT146 SMT3) 416-CDN88-044 3
Q605,Q606,Q909,Q910,
TRANSISTOR(2SC4695,SOT23,NPN) 416-DAIA-273 4
Q825, CHIP TRANSISTOR(DTA124TKAT146) 416-HDJ9700-210 1
IC204,IC404, IC(TC4053BFN/BU4053CF-E2/BU4053BCF,SOP-16) 417-2422MK2-695 2
IC808,
IC(74HC595D/74AHC595D/74AHC595DR/74HC595D@118/74HC595DT,SO-16)
417-HDJ9800-643 1
IC501, IC(NJM-2068M-TE2,SOP8) 417-M5-582 1
IC102,IC103,IC202,IC203,IC
302,IC303,IC402,IC403,IC5
02,IC621,IC901,IC902,IC61
3,IC614,
IC(BA15218F-E2,SOP-8) 417-QMX2-167 14
IC807, MIXER IC ASS'Y(CHECK SUM:ACF8*2) 704-D40-5286 1
IC(HD6473644RH,QFP-64) 417-QFX19-650 1
C157,C257,C357,C457,C72
3,C877,C882,C888,C903,C9
04,C515,
CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035 11
C129,C130,C229,C230,C32
9,C330,C429,C430,C512,
POLYESTER CAPACITOR(0.012uF/50V,J,TAPING) 413-3113-060 9
C881,
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING 5*7,MINI)(Cd,Pb,Hg,Cr)
413-HMA2200-5017 1
C123,C124,C131,C132,C22
3,C224,C231,C232,C323,C3
24,C331,C332,C423,C424,C
431,C432,C510,C513,
POLYESTER CAPACITOR(0.0047uF/100V,J,TAPING) 413-HT8015-159 18
C878,
ELEC. CAPACITOR(220uF/10V,M,105℃,TAPING 6.3*7,MINI)
413-HT801K-192 1
C695,C696,
ELEC. CAPACITOR(100uF/16V,M,105℃,TAPING 6.3*7,MINI)
413-HT801K-193 2
C501, CERAMIC CAPACITOR((100pF/50V,J,TAPING,SL) 413-PXE90-107 1
C687,C688,
E.C.(4.7uF/25V,MINI) 413-SMX701-712 2
18
