Reloop RMX-40 USB - Page 18

Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
R125,R126,R225,R226,R32
5,R326,R425,R426,
CHIP RESISTOR(270K OHM,1/8W,J,TP 0805,150V) 412-AMC110D-5077 8
R745,R746, CHIP RESISTOR(68K OHM,1/8W,0805,J,TP 150V) 412-CDMIX1-455 2
R503, CHIP RESISTOR(30K OHM,1/8W,J,TP 0805,150V) 412-CDMIX2-485 1
J03,J46,J60,J67,J69,J70,J8
7,J95,J180,J181,J224,J235,
J242,J254,J263,
CHIP RESISTOR(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414 15
R120,R220,R320,R420,R86
3,R868,R872,R905,R906,R9
09,R910,
CHIP RESISTOR( 3.9K OHM,1/8W, 0805,J,TP 150V) 412-DRM120-568 11
R878,R879,R880,R881,R88
2,R883,
CHIP RESISTOR(1K OHM,1/8W, 0805,J,TP 150V) 412-DV330-305 6
R560,R735,R737,R851,R85
4,R899,
CHIP RESISTOR(10K OHM,1/8W,0805,J,TP 150V) 412-DV330-306 6
R131,R132,R231,R232,R33
1,R332,R431,R432,R504,R8
92,
CHIP RESISTOR(100K OHM,1/8W, 0805,J,TP 150V) 412-DV330-307 10
R898, CHIP RESISTOR(1M OHM,1/8W, 0805,J,TP 150V) 412-DV330-308 1
R865,R866, CHIP RESISTOR(1.2K OHM,1/8W, 0805,J,TP,150V ) 412-DV330-309 2
R145,R245,R345,R445,
CHIP RESISTOR(20K OHM,1/8W,0805,J,TP ,150V) 412-DV330-311 4
R123,R124,R223,R224,R32
3,R324,R423,R424,R515,
CHIP RESISTOR( 2.2K OHM,1/8W,0805,J,TP 150V ) 412-DV330-313 9
R852, CHIP RESISTOR(22K OHM,1/8W, 0805,J,TP 150V) 412-DV330-314 1
R144,R244,R344,R444,R73
9,R740,
CHIP RESISTOR(27K OHM,1/8W,0805,J,TP 150V) 412-DV330-315 6
R747, CHIP RESISTOR(3.3K OHM,1/8W, 0805,J,TP,150V) 412-DV330-317 1
R520, CHIP RESISTOR(33K OHM,1/8W,0805,J,TP 150V) 412-DV330-318 1
R129,R130,R134,R229,R23
0,R234,R329,R330,R334,R4
29,R430,R434,R741,R871,R
742,
CHIP RESISTOR(4.7K OHM,1/8W,0805,J,TP 150V ) 412-DV330-320 15
R663,R664,R683,R684,R867,
CHIP RESISTOR(12K OHM,1/8W, 0805,J,TP,150V) 412-DV330-330 5
R121,R122,R221,R222,R32
1,R322,R421,R422,R506,R7
31,R732,
CHIP RESISTOR(15K OHM,1/8W,0805,J,TP 150V) 412-DV330-331 11
R577, CHIP RESISTOR( 220 OHM,1/8W,0805,J,TP 150V ) 412-DV330-333 1
R753,R754, CHIP RESISTOR(33 OHM,1/8W,0805,J,TP 150V) 412-DV330-334 2
R569,R570, CHIP RESISTOR(560 OHM,1/8W, 0805,J,TP,150V) 412-DV330-336 2
R137,R237,R337,R437,
CHIP RESISTOR(56K OHM,1/8W,0805,J,TP ,150V) 412-DV330-337 4
R501, CHIP RESISTOR(510 OHM,1/8W,J,TP 0805,150V) 412-QFX19-218 1
R551,R552,R553,R554,R55
5,R556,R557,R558,R559,R8
55,R856,R857,R858,R859,R
860,R861,
CHIP RESISTOR (1.5K OHM,1/8W, 0805,J,TP,150V ) 412-QMX1-035 16
R973,R974,R561,R562,R56
3,R564,R565,R566,R567,R5
68,R591,R592,
CHIP RESISTOR(2.7K OHM,1/8W, 0805,J,TP,150V) 412-QSPAND-496 12
