Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
D835,D837, INFRARED EMITTONG MODULE( LTE-302-M ) 410-CDMIX1-147 2
D832, DISPLAY(LTC-4624P-K1,30.02*12.8mm) 410-RMX30-262 1
D833, LED DISPLAY(LTC-4627P-22,25.27*10.16mm) 410-RMX40DSP-263 1
RB803,
THICK FILM RESISTOR NETWORKS(10K OHM,1/8W J,RA TYPE,7R8P)
412-DJ1-420 1
RB801,RB802,
THICK FILM RESISTOR NETWORKS(10K OHM,1/8W,J,RA TYPE,8R9P)
412-DV300-5143 2
C125,C126,C127,C128,C22
5,C226,C227,C228,C325,C3
26,C327,C328,C425,C426,C
427,C428,C509,C511,
POLYESTER CAPACITOR(0.1uF/63V,J,TAPING,MEM)
413-SPPW3-083A 18
C505,C519,
ELEC. CAPACITOR(47uF/25V,M,105℃,TAPING 6.3*7,MINI)(Cd,Pb,Hg,Cr)
413-SPPW3-237 2
D836,D838, PHOTO TRANSISTOR(LTR-301) 416-DCM270X-120 2
IC622, IC(NJM4556AD,DIP-8) 417-3113-018 1
IC06, IC(KIA78S08P-AT/P TO-92 ) 417-KT100-023 1
VR101,VR201,VR301,VR40
1,VR603,VR903,
VR(20KB*2,RK16K12D0023-20KB*2(HF)) 418-Q2221-084 6
VR501,VR801, VR(10KB,RK16K1150014-10KB(HF)) 418-Q2221-086 2
VR901, VR(50KMN*2,RK16K124A038-50KMN-(HF)) 418-Q2422-093 1
VR102,VR103,VR104,VR20
2,VR203,VR204,VR302,VR3
03,VR304,VR402,VR403,VR
404,VR601,VR602,
VR(50KB*2,RK16K124A027-50KB*2(HF)) 418-Q2422-094 14
VR502,VR503,VR504,
VR(50KB,RK16K1140133-50KB(HF)) 418-QMX1-081 3
CN04, 5P 2.54STRIP PIN HEADER(L=18mm,180°) 424-3433MK2-087 1
CN05, 4P 2.54STRIP PIN HEADER(L=18mm,180°) 424-40-127 1
CN906, 6P 2.54STRIP PIN HEADER(Pb,Cd) 424-40DSP-110 1
CN09, 10P 2.54STRIP PIN HEADER(Pb,Cd) 424-40DSP-111 1
CN901,
5P STRIP PIN HEADER(L=15mm,P=2.54mm,180 DEGREES)
424-CDMIX1-038 1
CN102,CN202,CN302,CN402,
4P STRIP PIN HEADER(L=15mm,P=2.54mm,180 DEGREES)
424-CDN24A-014 4
CN07,CN205,CN305,
4P2.54 STRIP PIN HEADER(L=15mm,180°) 424-CDU100-070 3
CN405, 3P2.54 STRIP PIN HEADER(L=15mm,180°) 424-DJS1200-079 1
CN105, 5P2.54 SERIES PIN HEADER(L=15mm,180°) 424-HPR1-077 1
CN905, 7P 2.54 STRIP PIN HEADER(L=15mm,180°) 424-RMX30-097 1
X802, CRYSTAL(XTAL 10MHz 32PF CYLINDER TYPE) 427-DJ1-057 1
SEGREGATE SHEET(t=0.3mm) 501-RMX40-1806 1
D820,D821,D822,D823,D82
4,D825,D826,D827,D828,D8
29,D830,D831,
LED HOLDER(LED-4.5A,H=4.5mm,WHITE) 504-BJ2300-039 12
D835,D836,D837,D838,
LED HOLDER(LED-10.6,H=10.7mm,WHITE) 504-CDMIX1-059 4
D832*3,D833*3, LED HOLDER(LED-9.5,H=9.5mm,WHITE) 504-HDJ11-123 6
D809,D804,D812,D817,D80
6,D814,D811,D805,D807,D8
08,D818,D810,D816,D604,D
605,D606,D813,D815,D601,
D602,D603,
LED HOLDER(LED-16A,H=16.4mm,WHITE) 504-Q2221-077 21
SCREW(3*5 P=0.5) 602-B300-041 5
R749,R750, CHIP RESISTOR(11K OHM,1/8W,J,TP 0805,150V) 412-40DSP-905 2
16
