Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
BEAT SW PCB ASS'Y 704-U40-6354 1
SW811,SW812, TACT SW(SKHHPN2910-HF,5PIN) 403-3113-017 2
CN06A, 4P2.54 STRIP PIN HEADER(L=15mm,180°) 424-CDU100-070 1
BEAT SW PCB 405-40USB-1776 1
R874, CHIP RESISTOR(1.2K OHM,1/8W, 0805,J,TP,150V ) 412-DV330-309 1
R870, CHIP RESISTOR(4.7K OHM,1/8W,0805,J,TP 150V ) 412-DV330-320 1
C890, CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311 1
MIXER PCB ASS'Y 704-U40-6355 1
SLEEVE(∮6*10.2L)
200-HPR1-331 5
VR SHEATH 300-SCX2-1125 2
SW804,SW805,SW806,SW8
07,SW808,SW809,SW810,S
W813,SW814,SW815,SW81
6,
PUSH SWITCH(SPEA12MC42-HF) 403-AK4-196A 11
SW202,SW402, LEVER SW(LBC22B-20KB,6PIN) 403-CDMIX1-114B 2
SW102,SW302, LEVER SW(LBC23M-20K,8PIN) 403-CDMIX1-115B 2
SW819, TACT SW(H=5mm,TAPING) 403-DCM270X-101A 1
SW821,SW822, SLIDE SW(SKA-22-09) 403-DRM120-154 2
SW901,SW607, SLIDE SW(SKA-22-12) 403-DRM120-154A 2
SW802, (DC11B2024420-(HF)) 403-QFX19-146 1
SW803, ROTARY SW(SR2512F-0110-20K0A-C9-S-3-097) 403-RMX40DSP-205 1
SW801, ROTARY SW(SR1712-0108-25K0A-N9-N) 403-RMX40DSP-206 1
SW817,SW818, ROTARY SW(SR1712-0105-20K0A-N9-N) 403-RMX40DSP-207 2
SW601,SW602,SW603,SW6
04,SW605,SW606,
LEVER SW(LBCR23M-20K) 403-T2-183 6
CN06, 4P 2.5 CONNECTOR(Cd,Pb) 404-40DSP-1951 1
CN10,CN11, 10P FFC CONNECTOR(SMD) 404-CDMIX2-1142 2
CN501,W103,W203,W303,
W403,
3P2.5 CONNECTOR WIRE(L=80mm,AWM2877 AWG26)
404-HPM11-1593 5
W08,
5P2.5 CONNECTOR WIRE( L=70mm,AWM2877,AWG26 )
404-HPM2-1490 1
CN03,
16P FFC CONNECTOR(16PIN P=1.0mm SMD FPC 2T-16P)
404-HV3423K-583 1
CN02, 18P FFC CONNECTOR(SMD,52207-1885) 404-RMX40-1947 1
W602,
3P2.5 CONNECTOR WIRE(L=150mm,AWM2877 AWG26)
404-T2-1687 1
CN01A, 26P 1.0 FFC CONNECTOR(52207-2685,SMD90°) 404-TU3-2834 1
CN10 TO CN10A,CN11 TO
CN11A,
10P FFC WIRE(P=1.0,170*11) 406-40DSP-754 2
W03A TO W03B, 1P WIRE(BROWN,UL1007,AWG26,L=320mm) 406-HT1016A-699 1
W01 TO W01A, LEAD WIRE 1007#26 L=200mm 5:5 ORG(TC) 406-HT7016-301 1
IC102 GND,IC302 GND, GOUND WIRE(L=200mm,UL1015#18 TS BLACK) 406-U40-853 2
D601,D602,D603,D604,D60
5,D606,D820,D821,D822,D8
23,D830,D804,D805,D806,D
807,D808,D809,D810,D811,
D812,D813,D814,D815,D81
6,D817,D818,
LED (6224-10ID-A,RED ) 410-CD6000-122A 26
D824,D825,D826,D827,D82
8,D829,D831,
LED ( GREEN ) 410-CD6000-124A 7
15
