Reloop RMX-40 USB - Page 15

Mixer & Dsp & Fader & Lever Meter & Sw PCB Ass'y
REF NO. DESCRIPTION PART NO. Q'TY REMARK
MIXER/DSP/FADER/LEVER METER/SW PCB ASS'Y 704-U40-6353 1
SCREW(3*5 P=0.5) 602-B300-041 8
PLASTIC SCREW(S-306-N66) 602-SPANDMK2-536 6
LEVER METER PCB ASS'Y 704-D40-8541 1
FIXED PILLAR(Cu,6*7mm) 200-RMX40-443 8
CN04A,
5P HEADER AND FEMALE HEADER SERIES CONNECTOR(P=2.54mm)
404-2422MK2-1813 1
CN05A, 4P 2.5 CONNECTOR(Cd,Pb) 404-40DSP-1951 1
D101,D201,D301,D401,D50
1,D901,D902,
LED BAR(LTA-10102M,RED/GREEN,25.27*5.08) 410-RMX40-264 7
D102,D202,D302,D402,D50
2,D903,D904,
LED BAR(LTA-1000G-NB,GREEN,25.27*5.08) 410-RMX40-265 7
C151,C251,C351,C451,C55
1,C961,C962,
ELEC. CAPACITOR(2.2uF/50V,M,105℃,TAPING 4*7,MINI)(Cd,Pb,Hg,Cr)
413-DV300-5156 7
C31,
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING 5*7,MINI)(Cd,Pb,Hg,Cr)
413-HMA2200-5017 1
C153,C154,C253,C254,C35
3,C354,C453,C454,C553,C5
54,C965,C966,C967,C968,
ELEC. CAPACITOR(10uF/25V,M,105℃,TAPING 4*7,MINI)(Cd,Pb,Hg,Cr)
413-SPPW3-235 14
IC106,IC107,IC206,IC207,IC
306,IC307,IC406,IC407,IC5
06,IC507,IC911,IC912,IC91
3,IC914,
IC(LA2284AL,SIP-9) 417-X3000-935 14
SCREW(DIAMETER3*3) 602-BD1550-283 8
LEVER METER PCB(94V0,FR-1,257.5*99*0.8t) 405-40DSP-1340A 1
R101,R102,R103,R104,R10
5,R106,R107,R108,R109,R1
10,R201,R202,R203,R204,R
205,R206,R207,R208,R209,
R210,R301,R302,R303,R30
4,R305,R306,R307,R308,R3
09,R310,R401,R402,R403,R
404,R405,R406,R407,R408,
R409,R410,R501,R502,R50
3,R504,R505,R506,R507,R5
08,R509,R510,R901,R902,R
903,R904,R905,R906,R907,
R908,R909,R910,R911,R91
2,R913,R914,R915,R916,R9
17,R918,R919,R920,
CHIP RESISTOR(180OHM,1/10W,F,TP 0603,50V) 412-900-1014 70
J01,J02,J06,J13,J14,J15,J1
6,J17,J18,J19,J20,J21,J22,J
33,J34,J35,
CHIP RESISTOR(0 OHM,1/8W,1206,J,TP ,150V) 412-DJ3000-414 16
R171,R271,R371,R471,R52
4,R983,R984,
CHIP RESISTOR( 3.9K OHM,1/8W, 0805,J,TP 150V) 412-DRM120-568 7
R173,R174,R273,R274,R37
3,R374,R473,R474,R523,R5
26,R574,R981,R982,R987,R
989,R990,R988,
CHIP RESISTOR(10K OHM,1/8W,0805,J,TP 150V) 412-DV330-306 17
R172,R272,R372,R472,R52
5,R985,R986,
CHIP RESISTOR (470 OHM,1/8W, 0805,J,TP,150V) 412-VCDG3-395 7
C152,C252,C452,C552,C96
3,C964,C352,
CHIP CAPACITOR(0.1uF/ 50V,Z,0805 TYPE,Y5V) 413-DV330-313 7
14
