Reloop RMX-40 USB Service Manual

Usb PCB Ass'y Part List
REF NO. DESCRIPTION PART NO. Q'TY REMARK
R01,R915,R916,R925,R926,
CARBON FILM RESISTOR(4.7K OHM,1/6W,J,T-26) 412-3113-055 5
R473, CARBON FILM RESISTOR(470 OHM,1/6W,J,T-26) 412-3113-056 1
R723,R724,R773,R774,R95
3,R954,R969,R970,R959,R9
60,
CARBON FILM RESISTOR(22K OHM,1/6W,J,T-26) 412-3113-059 10
R477,R478, CARBON FILM RESISTOR(100 OHM,1/6W,J,T-26) 412-3113-060 2
R474, CARBON FILM RESISTOR((47K OHM,1/6W,J,T-26) 412-3113-063 1
R475,R923,R924, CARBON FILM RESISTOR(10K OHM,1/6W,J,T-26) 412-3113-068 3
R02, CARBON FILM RESISTOR((2.7K OHM,1/6W,J,T-26) 412-3113-073 1
R479,R913,R914, CARBON FILM RESISTOR(1K OHM,1/6W,J,T-26) 412-3113-078 3
R921,R922, CARBON FILM RESISTOR((3K OHM,1/6W,J,T-26) 412-CDN22A-373 2
R05, CARBON FILM RESISTOR(1 OHM,1/4W,J,T-52) 412-CDN34A-388 1
R917,R918, CARBON FILM RSISTOR(11K OHM,1/6W,J,T-26) 412-DCM370E3-436 2
R919,R920, CARBON FILM RESISTOR(6.2K OHM,1/6W,J,T-26) 412-HV3363K-349 2
R955,R956, CARBON FILM RESISTOR(5.1K OHM,1/6W,J,T-26) 412-KM281-294 2
R07, CARBON FILM RESISTOR(4.7 OHM,1/4W,J,T-52) 412-KM501-293 1
R06, CARBON FILM RESISTOR(82 OHM,1/6W,J,T-26) 412-PMSE1-152 1
R476, CARBON FILM RESISTOR(20K OHM,1/6W,J,T-26) 412-STR880-482 1
D701,D751, SWITCHING DIODE(1N4148,1/2W,150mA/100V,T-77) 414-2002-002 2
D03,D04, SWITCHING DIODE( ISS133 T-77) 414-3113-005 2
ZD01, ZENER DIODE(MTZJ5.6-B,1/2W,T-77) 414-HT8033-032 1
ZD02, ZENER DIODE(MTZJ10-BT,1/2W,T-77) 414-SPPW3-061 1
L702,L752, BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 2
13
