Usb PCB Ass'y Part List
REF NO. DESCRIPTION PART NO. Q'TY REMARK
C704,C717,C718,C728,C75
4,C767,C768,C778,
CHIP CAPACITOR(0.47uF/50V,Z,0805 TYPE,Y5V) 413-CDN88-078 8
C701,C702,C751,C752,
CHIP CAPACITOR (27pF/50V,J,0805 TYPE,NPO) 413-CDN88-128 4
C713,C714,C763,C764,
CHIP CAPACITOR(1000pF/50V,J,0805 TYPE,NPO) 413-DV330-311 4
C787,C737,C468,C724,C93
5,C936,
CHIP CAPACITOR(0.01uF/50V,K,0805 TYPE,X7R) 413-DV330-312 6
C710,C711,C726,C730,C76
0,C761,C776,C780,C723,C7
73,
CHIP CAPACITOR(0.1uF/ 50V,Z,0805 TYPE,Y5V) 413-DV330-313 10
C703,C712,C727,C731,C75
3,C762,C777,C781,
CHIP CAPACITOR(0.22uF/50V,Z,0805 TYPE,Y5V) 413-DV330-318 8
C721,C722,C771,C772,
CHIP CAPACITOR(150pF/50V,J,0805 TYPE,NPO) 413-HV3500K-353 4
L701,L703,L704,L751,L753,
L754,
CHIP BEAD(SBK201209T-601Y-N) 415-1300-240 6
CHIP BEAD(FBMA-11-201209-601A03T,600Ω/100MHz)
415-1300-240A 0
IC411, IC(NJM-2068M-TE2,SOP8) 417-M5-582 1
IC907, IC(NJM-2060V-TE1,SMD SSOP-14) 417-PRO1000-502 1
IC702,IC752,IC903,IC904,IC
905,
IC(BA15218F-E2,SOP-8) 417-QMX2-167 5
IC701,IC751, IC(UAC3556B) 417-U40-776 2
C464, CERAMIC CAPACITOR(33pF/50V,J,TAPING,NPO) 413-3113-029 1
C07,C08,C11,C13,C911,C9
12,C919,C942,C719,C720,C
769,C770,
CERAMIC CAPACITOR(0.1uF/50V,Z,TAPING,Y5V) 413-3113-035 12
C951,C952, CERAMIC CAPACITOR(470pF/50V,K,TAPING,Y5P) 413-3113-036 2
C12,C14,C16,
ELEC. CAPACITOR(100uF/10V,M,105℃,TAPING 5*11)(Cd,Pb,Hg,Cr)
413-3113-046 3
C467,C709,C729,C759,C77
9,C725,C775,C732,C782,
ELEC. CAPACTIOR(10uF/25V,M,105℃,TAPING 5*11)
413-3113-052 9
C04,
ELEC. CAPACITOR(220uF/25V,M, 105℃,TAPING 8*12)(Cd,Pb,Hg,Cr)
413-DV300-292 1
C707,C708,C757,C758,
ELEC. CAPACITOR ( 47uF/25V M 105℃, TAPING 5*11 )(Cd,Pb,Hg,Cr)
413-HS100-181 4
C05,C913,C914,C915,C916,
C917,C918,C943,C944,C94
7,C948,
ELEC. CAPACITOR(22uF/16V,M,105℃,TAPING 5*11)
413-HT8015-163 11
C15,
ELEC. CAPACITOR(220uF/10V,M,105℃,TAPING 6.3*11)(Cd,Pb,Hg,Cr)
413-KC220-119 1
C463, CERAMIC CAPACITOR(15pF/50V,J,TAPING,NPO) 413-KM280-173 1
C462,
ELEC. CAPACITOR(47uF/16V,M,105℃,TAPING 5*11)
413-KT350-085 1
C461,C909,C910, CERAMIC CAPACITOR((100pF/50V,J,TAPING,SL) 413-PXE90-107 3
C09,C10,C465,C466,
ELEC.CAPACITOR(100uF/16V,M,105℃,TAPING 5*11)
413-PXE90-109 4
Q04,
TRANSISTOR(2SD1384(R)/2SD1207U, OR.TAPING,TO-92L)
416-1360S-016 1
Q01, TRANSISTOR(2SC1740STPR TAPING) 416-3113-007 1
Q907,Q908, TRANSISTOR((2SC2878-B TO-92 (TE2.M) 416-AMC110A-5017 2
Q03, TRANSISTOR(TR DTA124TSATP) 416-KE200S-024 1
USB PCB 405-40USB-1770 1
R03,R08, CARBON FILM RESISTOR(100K OHM,1/6W,J,T-26) 412-3113-047 2
R04,R471, CARBON FILM RESISTOR(2.2K OHM,1/6W,J,T-26) 412-3113-048 2
12
